Infiniti QX80 I facelift 3 (2020-2024) aiming motor gnd Wiring diagram
This page shows the only wiring diagram for the component.aiming motor gnd, which is found in the car Infiniti QX80 I facelift 3 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram aiming motor gnd (1 of 1)
AFS CONTROL UNIT
AIMING MOTOR DRIVE SIG
AIMING MOTOR GND
AMPLIFIER
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/YEL WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
FRONT HEIGHT SENSOR
FRONT HEIGHT SENSOR SIG
FUSE 3
FUSE 6
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
GRY/BLU WIRE
HEIGHT SENSOR GND
HEIGHT SENSOR PWR SUPPLY
HOT AT ALL TIMES
HOT W/ IGNITION RELAY 1 ENERGIZED
IGN PWR SUPPLY
LCU
LEFT FRONT COMBINATION LAMP
LEFT HEADLAMP AIMING MOTOR
LT BLU WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
PNK WIRE
PPL
REAR HEIGHT SENSOR
REAR HEIGHT SENSOR SIG
RED/GRN WIRE
RIGHT FRONT COMBINATION LAMP
RIGHT HEADLAMP AIMING MOTOR
SWIVEL ACTUATOR GND
SWIVEL ACTUATOR LIN SIG
SWIVEL MOTOR LEFT HEADLAMP SWIVEL ACTUATOR
SWIVEL MOTOR RIGHT HEADLAMP SWIVEL ACTUATOR
SWIVEL POSITION SENSOR
UNIFIED METER
YEL WIRE
Go to component -> Adaptive front lighting circuit -> AIMING MOTOR GND
