Infiniti QX80 I facelift 3 (2020-2024) accessory pre-wire connector 1 Wiring diagrams
This page contains all the electrical diagrams for the component. accessory pre-wire connector 1, in which he is found in the car Infiniti QX80 I facelift 3 (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram accessory pre-wire connector 1 (1 of 4)
A/C AUTO AMPLIFIER
A/T SHIFT SELECTOR
ACCESSORY PRE-WIRE CONNECTOR 1
ACCESSORY RELAY
AIR BAG DIAGNOSIS SENSOR UNIT
AROUND VIEW MONITOR CONTROL UNIT
AUTO ANTI-DAZZLING INSIDE MIRROR
AUTOMATIC BACK DOOR MAIN SWITCH
AV CONTROL UNIT
BCM (BODY CONTROL MODULE)
BLK WIRE
BLOWER RELAY
COMBINATION METER
DATA LINK CONNECTOR
DISPLAY UNIT
DRIVER SIDE DOOR MIRROR
DRIVER SIDE FRONT DOOR GRIP MOOD LAMP
DRIVER SIDE FRONT DOOR LOCK ASSEMBLY
DRIVER SIDE FRONT DOOR REQUEST SWITCH
DRIVER SIDE VANITY MIRROR LAMP
FRONT BLOWER MOTOR
GLOVE BOX LAMP)
HEADLAMP AIMING SWITCH
IGNITION RELAY 1
IGNITION RELAY 2
INTEGRAL SWITCH
IONIZER
LANE CAMERA UNIT
LEFT REAR CENTER CONSOLE USB POWER SOCKET
LEFT SECOND HEATED SEAT SWITCH
LOW TIRE PRESSURE WARNING CONTROL UNIT
LT BLU WIRE
MAP LAMP
NATS ANTENNA AMPLIFIER
NCA WIRE
ORG/ WIRE
PASSENGER SIDE DOOR MIRROR
PASSENGER SIDE VANITY MIRROR LAMP
PERSONAL LAMP
PNK WIRE
POWER STEERING CONTROL UNIT
POWER WINDOW MAIN SWITCH
PRESET SWITCH
PUSH BUTTON IGNITION SWITCH
RAIN SENSOR
REAR A/C CONTROL
REAR CONSOLE POWER SOCKET
RIGHT REAR CENTER CONSOLE USB POWER SOCKET
RIGHT SECOND HEATED SEAT SWITCH
SEAT MEMORY SWITCH
SHIELD
SMART REAR VIEW MIRROR
SNOW MODE/ TOW MODE/ VDC OFF SWITCH ASSEMBLY
SONAR CONTROL UNIT
SONAR CONTROL UNIT SHIELD
STEERING ANGLE SENSOR
SUNROOF MOTOR ASSEMBLY,
SUNROOF SWITCH
TCU
TILT, TELESCOPIC SWITCH
TO INTAKE DOOR MOTOR (DIAGRAM 4 OF 4)
TRIPLE SWITCH
TWIN SWITCH
USB CONNECTOR
W/ SMART REAR VIEW MIRROR
W/O HEATER, VENTILATION SEAT SYSTEM
W/O SMART REAR VIEW MIRROR
YAW RATE/ SIDE DECEL G SENSOR
YEL WIRE
Go to component -> Ground distribution circuit (3 of 4) -> ACCESSORY PRE-WIRE CONNECTOR 1
Wiring diagram accessory pre-wire connector 1 (2 of 4)
A/C AUTO AMPLIFIER
ACCESSORY PRE-WIRE CONNECTOR 1
AFS CONTROL UNIT
AIR BAG DIAGNOSIS SENSOR UNIT
AROUND VIEW MONITOR CONTROL UNIT
AUTO ANTI-DAZZLING INSIDE MIRROR
AUTOMATIC BACK DOOR CONTROL MODULE
AV CONTROL UNIT
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
COMBINATION METER
COMBINATION SWITCH
DATA LINK CONNECTOR
EXHAUST GAS/OUTSIDE DOOR DETECTING SENSOR
FROM FUSE 11 (DIAGRAM 2 OF 8)
FROM FUSE, FUSIBLE LINK BLOCK (DIAGRAM 1 OF 8)
FRONT SEAT (DRIVER SIDE)
FRONT SEAT (PASSENGER SIDE)
FUSE 1
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 2
FUSE 3
FUSE 4
GRN WIRE
GRY WIRE
HEATER, VENTILATION SEAT RELAY
ICC BRAKE SWITCH
IGNITION RELAY 1
IGNITION RELAY 2
IONIZER (W/ ACCS)
LEFT FRONT COMBINATION LAMP
LEFT HEADLAMP AIMING MOTOR
LEFT HEADLAMP SWIVEL ACTUATOR
LEFT SECOND HEATED SEAT SWITCH
LOW TIRE PRESSURE WARNING CONTROL UNIT
NCA WIRE
OCCUPANT DETECTION SYSTEM CONTROL UNIT
POWER STEERING CONTROL UNIT
REAR A/C CONTROL
REAR A/C RELAY
REAR BLOWER MOTOR
RED WIRE
REMOTE ENGINE START RELAY
RIGHT FRONT COMBINATION LAMP
RIGHT HEADLAMP AIMING MOTOR
RIGHT HEADLAMP SWIVEL ACTUATOR
RIGHT SECOND HEATED SEAT SWITCH
SMART REAR VIEW MIRROR
SNOW MODE/ TOW MODE/VDC OFF SWITCH ASSEMBLY
SONAR CONTROL UNIT
STEERING ANGLE SENSOR
STOP LAMP SWITCH
TCU (IF EQUIPPED)
TO ACCESSORY RELAY (DIAGRAM 2 OF 8)
W/ ACTIVE AFS
W/ FRONT HEATED SEAT
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (5 of 8) -> ACCESSORY PRE-WIRE CONNECTOR 1
Wiring diagram accessory pre-wire connector 1 (3 of 4)
A/C AUTO AMPLIFIER
ACCESSORY PRE-WIRE CONNECTOR 1
ACCESSORY RELAY 2
AROUND VIEW MONITOR CONTROL UNIT
AUTO ANTI-DAZZLING INSIDE MIRROR
BLK WIRE
BLU WIRE
BOSE AMP (17 SPEAKERS)
BRN WIRE
COMBINATION METER
DATA LINK CONNECTOR
FROM FUSE 8 (DIAGRAM 2 OF 8)
FROM FUSE BLOCK (J/B) (DIAGRAM 2 OF 8)
FROM FUSE, FUSIBLE LINK HOLDER 4 (DIAGRAM 4 OF 8)
FRONT POWER SOCKET
FUSE 12
FUSE 6
FUSE BLOCK (J/B) (LEFT END OF DASH)
GRN WIRE
INTEGRAL SWITCH
INTELLIGENT KEY WARNING BUZZER
POWER WINDOW MAIN SWITCH (DOOR MIRROR REMOTE CONTROL SWITCH)
PPL
PRESET SWITCH
REAR CONSOLE POWER SOCKET
SECOND SEAT POWER UNLOCK SWITCH
SMART REAR VIEW MIRROR
TCU (IF EQUIPPED)
TO ACCESSORY PRE-WIRE CONNECTOR (LEFT HEADREST DISPLAY UNIT) (DIAGRAM 8 OF 8)
TO USB RELAY (DIAGRAM 8 OF 8)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (7 of 8) -> ACCESSORY PRE-WIRE CONNECTOR 1
Wiring diagram accessory pre-wire connector 1 (4 of 4)
ACCESSORY PRE WIRE (SCUFF PLATE)
ACCESSORY PRE-WIRE CONNECTOR 1
BACK DOOR SW
BAT (F/L)
BAT (FUSE) ROOM LAMP TIMER CONT
BCM (BODY CONTROL MODULE) (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/YEL WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
FUSE 10
FUSE 3
FUSE 6
FUSE 84
FUSE 86
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK HOLDER 5
FUSE, FUSIBLE LINK, RELAY BOX
FUSIBLE LINK V
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY 1 ENERGIZED
INT ROOM LAMP PWR SPLY
LEFT FRONT KICKING PLATE ILLUMINATION
LEFT REAR KICKING PLATE ILLUMINATION
LH CONT TRAILER TURN SIG
LT GRN WIRE
LUGGAGE ROOM LAMP CONT
MAP L
ORG/BLU WIRE
PNK WIRE
PPL
RED WIRE
RED/GRN WIRE
RH CONT TRAILER TURN SIG
RIGHT FRONT KICKING PLATE ILLUMINATION
RIGHT REAR KICKING PLATE ILLUMINATION
TRAILER POWER RELAY (FUSE, FUSIBLE LINK, RELAY BOX)
TRAILER TAIL LAMP RELAY
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Trailer tow circuit (1 of 2) -> ACCESSORY PRE-WIRE CONNECTOR 1
