Car Wiring Diagrams for Third row folding seat circuit for Infiniti QX80 I (2013-2014)
Third row folding seat circuit
BACK- WARD
BLK WIRE
BLU WIRE
FOR- WARD
FUSE 9
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK HOLDER 2
FUSIBLE LINK S
GRN WIRE
HOT AT ALL TIMES
LEFT DOWN RELAY 1
LEFT DOWN RELAY 2
LEFT FOLD DOWN SWITCH
LEFT FOLDING MOTOR
LEFT RECLINING SWITCH
LEFT THIRD SEAT
LEFT UP RELAY 1
LEFT UP RELAY 2
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/BLU WIRE
RIGHT DOWN RELAY 1
RIGHT DOWN RELAY 2
RIGHT FOLD DOWN SWITCH
RIGHT FOLDING MOTOR
RIGHT RECLINING SWITCH
RIGHT THIRD SEAT
RIGHT UP RELAY 1
RIGHT UP RELAY 2
WHT WIRE
YEL WIRE
