Car Wiring Diagrams for Immobilizer circuit for Infiniti QX80 I (2013-2014)

+IG BAT (F/L) BAT FUSE BATTERY TERMINAL W/ FUSIBLE LINK BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BLU/BLK WIRE CAN COMMUNICATION LINE PNK CAN COMMUNICATION LINE WIRE CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM CRANKING REQUEST DATA ECM (ENGINE CONTROL MODULE) FUSE 10 FUSE 3 FUSE 43 FUSE 6 FUSE 7 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX FUSIBLE LINK C FUSIBLE LINK K GRN WIRE GRY WIRE GRY/RED WIRE H/LP HI H/LP LO HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN ON OR START IGNITION RELAY IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LT GRN WIRE LT GRN/RED WIRE NATS ANT AMP NATS ANTENNA AMPLIFIER ORG/BLU WIRE PNK CLK WIRE PNK WIRE SECURITY IND SECURITY IND CONT STOP LAMP SW 2 UNIFIED METER CONTROL UNIT YEL WIRE
