Infiniti QX80 I (2013-2014) vdc off ind, abs ind brake ind, vdc ind Wiring diagram
This page shows the only wiring diagram for the component.vdc off ind, abs ind brake ind, vdc ind, which is found in the car Infiniti QX80 I (2013-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vdc off ind, abs ind brake ind, vdc ind (1 of 1)
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE FLUID LEVEL SW
BRAKE FLUID LEVEL SWITCH
BRN WIRE
CAN L
CAN-H
CAN-H PNK CAN-L WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DP FL
DP FR
DP RL
DP RR
DS FL
DS FR
DS RL
DS RR
FUSE 3
FUSE 57
FUSE 7
FUSE 74
FUSE BLOCK (J/B)
FUSE L
FUSE M
FUSE, FUSIBLE LINK BLOCK
FUSE, FUSIBLE LINK HOLDER 1
FUSE, FUSIBLE LINK, RELAY BOX
GND 3
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN
IGN 2
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT FRONT WHEEL SPEED SENSOR
LEFT REAR WHEEL SPEED SENSOR
LT BLU WIRE
LT GRN WIRE
MTR PWR 2
MTR SUPPLY
ORG/ WIRE
PARKING BRAKE SWITCH
PNK WIRE
PNK/BLK WIRE
PPL
PWR
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RIGHT FRONT WHEEL SPEED SENSOR
RIGHT REAR WHEEL SPEED SENSOR
SIG
SNOW MODE/TOW MODE/ VDC OFF SWITCH ASSEMBLY
STEERING ANGLE SENSOR
STOP LAMP RELAY
STOP LAMP SW ON
STOP LAMP SWITCH
STP 2
VDC OFF IND, ABS IND BRAKE IND, VDC IND
VDC OFF SW
VDC OFF SWITCH
WHT WIRE
WHT/BLK WIRE
YAW RATE/SIDE/DECEL G SENSOR
Go to component -> Anti-lock brakes circuit -> VDC OFF IND, ABS IND BRAKE IND, VDC IND
