Infiniti QX80 I (2013-2014) thrt pos sens 1 Wiring diagram
This page shows the only wiring diagram for the component.thrt pos sens 1, which is found in the car Infiniti QX80 I (2013-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram thrt pos sens 1 (1 of 1)
A/F SENS 1
A/F SENS 1 (BANK 2)
A/F SENS 1 HTR
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN/WHT WIRE
CAMSHAFT POS SENS
CAMSHAFT POSITION SENSOR (BANK 1)
CAMSHAFT POSITION SENSOR (BANK 2)
CRNKSHFT POS SENS
CTRL SOL VALVE
ECM (ENGINE CONTROL MODULE)
ELECTRIC THROTTLE CONTROL ACTUATOR
EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
FUEL INJ 1 (HI)
FUEL INJ 1 (LO)
FUEL INJ 4 (HI)
FUEL INJ 4 (LO)
FUEL INJ 6 (HI)
FUEL INJ 6 (LO)
FUEL INJ 7 (HI)
FUEL INJ 7 (LO)
FUEL INJECTOR 1
FUEL INJECTOR 4
FUEL INJECTOR 6
FUEL INJECTOR 7
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/RED WIRE
HEATED OXYGEN SENS
HI PRESS FUEL PUMP
HIGH PRESSURE FUEL PUMP
LT BLU WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
NCA WIRE
PNK CAMSHAFT POS SENS WIRE
PNK WIRE
PPL
PPL ABSOLUTE PRESS SENS
PPL/WHT WIRE
RED WIRE
RED/WHT WIRE
SENS GND
SENS PWR SPLY
SENSOR 1
SENSOR 2
SHIELD
THROT POS SENS 2
THROTTLE CONTROL MOTOR
THROTTLE POSITION SENSOR
THRT CTRL MTR (CLS)
THRT CTRL MTR (OPEN)
THRT POS SENS 1
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 5.6l (4 of 7) -> THRT POS SENS 1
