Infiniti QX80 I (2013-2014) right second seat power unlock switch Wiring diagram
This page shows the only wiring diagram for the component.right second seat power unlock switch, which is found in the car Infiniti QX80 I (2013-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right second seat power unlock switch (1 of 1)
BLK WIRE
BLU/WHT WIRE
FUSE 6
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK HOLDER 2
FUSIBLE LINK S
GRN WIRE
HOT AT ALL TIMES
LEFT POWER UNLOCK MOTOR
LEFT POWER UNLOCK RELAY
LEFT SECOND SEAT
LEFT SECOND SEAT POWER UNLOCK SWITCH
PNK/BLK WIRE
RED WIRE
RIGHT POWER UNLOCK MOTOR
RIGHT POWER UNLOCK RELAY
RIGHT SECOND SEAT
RIGHT SECOND SEAT POWER UNLOCK SWITCH
YEL WIRE
Go to component -> Second row seat release circuit -> RIGHT SECOND SEAT POWER UNLOCK SWITCH
