Infiniti QX80 I (2013-2014) right second seat Wiring diagrams
This page contains all the electrical diagrams for the component. right second seat, in which he is found in the car Infiniti QX80 I (2013-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
right second seat wiring diagram (1 of 2)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
FUSE 14
FUSE 15
FUSE BLOCK (J/B)
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT W/ IGNITION RELAY-2 ENERGIZED
ILLUM
LEFT SEAT BACK HEATER
LEFT SEAT CUSHION HEATER
LEFT SECOND HEATED SEAT SWITCH
LEFT SECOND SEAT
LOW HIGH OFF
LOW OFF
MAIN HEATER
ORG/ WIRE
PPL
RED WIRE
RIGHT SEAT BACK HEATER
RIGHT SEAT CUSHION HEATER
RIGHT SECOND HEATED SEAT SWITCH
RIGHT SECOND SEAT
SUB HEATER
THERM- OSTAT
WHT WIRE
Go to component -> Heated seats circuit (1 of 2) -> RIGHT SECOND SEAT
right second seat wiring diagram (2 of 2)
BLK WIRE
BLU/WHT WIRE
FUSE 6
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK HOLDER 2
FUSIBLE LINK S
GRN WIRE
HOT AT ALL TIMES
LEFT POWER UNLOCK MOTOR
LEFT POWER UNLOCK RELAY
LEFT SECOND SEAT
LEFT SECOND SEAT POWER UNLOCK SWITCH
PNK/BLK WIRE
RED WIRE
RIGHT POWER UNLOCK MOTOR
RIGHT POWER UNLOCK RELAY
RIGHT SECOND SEAT
RIGHT SECOND SEAT POWER UNLOCK SWITCH
YEL WIRE
Go to component -> Second row seat release circuit -> RIGHT SECOND SEAT
