Infiniti QX80 I (2013-2014) pass door sw Wiring diagram
This page shows the only wiring diagram for the component.pass door sw, which is found in the car Infiniti QX80 I (2013-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass door sw (1 of 1)
BAT (F/L)
BAT FUSE
BLK WIRE
BLK/YEL WIRE
BODY CONTROL MODULE (BCM)
CLOSE SW
COMBINATION METER
DOWN/OPEN
DRIVER DOOR SW
DRIVER SIDE FRONT DOOR SWITCH
FUSE 10
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX
FUSIBLE LINK K
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
IGN
LT BLU WIRE
LT GRN WIRE
MODULE
ORG/ WIRE
PASS DOOR SW
PASSENGER SIDE FRONT DOOR SWITCH
PNK OPEN SW WIRE
PNK WIRE
POWER WINDOW MAIN SWITCH
PW PWR SPLY (BAT)
PW PWR SPLY (IGN)
SUNROOF MOTOR ASSEMBLY,
SUNROOF SWITCH
UP/CLOSE
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> PASS DOOR SW
