Infiniti QX80 I (2013-2014) fuse, fusible holder 6 Wiring diagram
This page shows the only wiring diagram for the component.fuse, fusible holder 6, which is found in the car Infiniti QX80 I (2013-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse, fusible holder 6 (1 of 1)
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM
BATTERY
BATTERY TERMINAL W/ FUSIBLE LINK
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CRUISE CONTROL SYSTEM
ELECTRONIC SUSPENSION SYSTEM
ENGINE CONTROLS SYSTEM
FROM FUSE BLOCK J/B (DIAGRAM 3 OF 3)
FUSE 31
FUSE 32
FUSE 33
FUSE 34
FUSE 35
FUSE 36
FUSE 37
FUSE 38
FUSE 76
FUSE 77
FUSE 79
FUSE 81
FUSE 82
FUSE 83
FUSE 84
FUSE 85
FUSE 86
FUSE 87
FUSE, FUSIBLE HOLDER 6
FUSE, FUSIBLE LINK HOLDER 2
FUSE, FUSIBLE LINK HOLDER 3
FUSE, FUSIBLE LINK HOLDER 4
FUSE, FUSIBLE LINK HOLDER 5
FUSE, FUSIBLE LINK, RELAY BOX
FUSIBLE LINK A
FUSIBLE LINK B
FUSIBLE LINK C
FUSIBLE LINK D
FUSIBLE LINK E
FUSIBLE LINK F
FUSIBLE LINK G
FUSIBLE LINK H
FUSIBLE LINK HOLDER 1
FUSIBLE LINK HOLDER 2
FUSIBLE LINK I
FUSIBLE LINK J
FUSIBLE LINK K
FUSIBLE LINK L
FUSIBLE LINK M
FUSIBLE LINK N
FUSIBLE LINK O
FUSIBLE LINK P
FUSIBLE LINK Q
FUSIBLE LINK R
FUSIBLE LINK S
FUSIBLE LINK T
FUSIBLE LINK U
FUSIBLE LINK V
GRN WIRE
GRN/RED WIRE
GRY WIRE
HORNS SYSTEM
INVERTER UNIT
NAVIGATION, SOUND SYSTEMS
NCA WIRE
OPTION CONNECTOR (ELECTRIC BRAKE)
ORG/ WIRE
PASSIVE RESTRAINTS SYSTEM
PNK WIRE
RED WIRE
SEATS SYSTEM
SEATS, MEMORY, BODY COMPUTER SYSTEMS
STARTING/ CHARGING SYSTEM
SW IND
SW SIG
TO FUSE BLOCK (J/B) (DIAGRAM 2 OF 3)
TO FUSE BLOCK (J/B) (DIAGRAM 3 OF 3)
TO IGNITION RELAY (DIAGRAM 3 OF 3)
TO IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) (DIAGRAM 3 OF 3)
TRANSMISSIONS SYSTEM
TRUNK, TAILGATE, FUEL DOORS SYSTEM
W/ REAR ENTERTAINMENT
WHT WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit (1 of 3) -> FUSE, FUSIBLE HOLDER 6
