Infiniti QX80 I (2013-2014) driver seat control unit driver side front seat Wiring diagram
This page shows the only wiring diagram for the component.driver seat control unit driver side front seat, which is found in the car Infiniti QX80 I (2013-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver seat control unit driver side front seat (1 of 1)
AROUND VIEW MONITOR CONTROL UNIT
AV COMM (H)
AV COMM (L)
AV CONTROL UNIT (BELOW CENTER OF DASH)
BLK WIRE
BLU WIRE
BOSE AMPLIFIER (W/ 15-SPEAKERS)
BRN WIRE
CAN-H
CAN-L AV COMM (H)
CPU PNK WIRE
DRIVER SEAT CONTROL UNIT DRIVER SIDE FRONT SEAT
GRN WIRE
ICC SENSOR
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
ITS COMM-H
ITS COMM-L
LEFT HARDEST DISPLAY UNIT
LT BLU WIRE
LT GRN WIRE
MULTI- FUNCTION SWITCH
PASSENGER SIDE FRONT SEAT (W/ REAR ENTERTAINMENT)
PNK WIRE
PPL CAN-L
RED WIRE
RED/YEL WIRE
RIGHT HARDEST DISPLAY UNIT
SHIELD
W/ REAR ENTERTAINMENT
W/O REAR ENTERTAINMENT
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit (3 of 3) -> DRIVER SEAT CONTROL UNIT DRIVER SIDE FRONT SEAT
