Infiniti QX80 I (2013-2014) dimmer signal Wiring diagram

AV CONTROL UNIT BAT (F/L) BAT FUSE BCM (BODY CONTROL MODULE) BLK WIRE BLK/ORG WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BLU/WHT WIRE BRN/YEL WIRE CAN L CAN-H COMB SW OUT 1 COMB SW OUT 2 COMB SW OUT 3 COMBI SW IN 1 COMBI SW IN 2 COMBI SW IN 3 COMBI SW IN 4 COMBI SW IN 5 COMBI SW OUT 4 COMBI SW OUT 5 COMBINATION METER COMBINATION SWITCH COMPUTER DATA LINES SYSTEM DIMMER SIGNAL DIODE FUSE 10 FUSE 3 FUSE 6 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX FUSIBLE LINK K GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START ILLUMI- NATION ILLUMINATION ILLUMINATION CONTROL SWITCH INPUT 1 INPUT 2 INPUT 3 INPUT 4 INPUT 5 PPL OUT 1 LOW SIDE PUSH LED LT BLU WIRE LT GRN WIRE OPTICAL SENSOR ORG/ WIRE OUT 2 + OUT 3 OUT 4 OUT 5 OUTPUT PNK WIRE PNK/BLK WIRE POWER PPL PUSH BTN IGN SW ILL PWR PUSH BUTTON IGNITION SWITCH RECEIVER, SENS GND RED WIRE RED/WHT WIRE SENS PWR SPLY TRIP RESET, ILLUMINATION CONTROL SWITCH UNIFIED METER CONTROL UNIT (W/ METER ILLUMINATION) WHT WIRE YEL WIRE YEL/GRN WIRE
