Infiniti QX80 I (2013-2014) composite img sig gnd pnk composite img sig Wiring diagrams

This page contains all the electrical diagrams for the component. composite img sig gnd pnk composite img sig, in which he is found in the car Infiniti QX80 I (2013-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram composite img sig gnd pnk composite img sig (1 of 4)

Wiring diagram composite img sig gnd pnk composite img sig for Infiniti QX80 I (2013-2014) (1 of 4)

Get access

AUX IMG SIG AV CONTROL UNIT (BELOW CENTER OF DASH) BACK BLK WIRE BLU WIRE BOSE AMPLIFIER ON SIGNAL COMBINATION SWITCH (SPIRAL CABLE) COMPOSITE IMG SIG GND PNK COMPOSITE IMG SIG WIRE DISK EJECT SIG ENTER FUSE 19 FUSE 4 FUSE 5 FUSE 8 FUSE 9 FUSE BLOCK (J/B) GRN WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START LF SND SIG(+) PNK LF SND SIG(-) WIRE LR SND SIG(-) LT GRN WIRE MENU DOWN MENU UP MODE CHANGE SIG NCA WIRE ORG/ WIRE PNK WIRE PPL PPL AUX IMG GND SHIELD SHIELD PPL LR SND SIG(+) RED WIRE RED/WHT WIRE RF SND SIG(-) RR SND SIG(-) SHIELD SHIELD SHIELD SOURCE STEERING SWITCH STRG SW A PPL STRG_SW_B STRG_SW_GND SWITCH GND TEL UP VOICE VOLUME DOWN VOLUME- W/ TELEMATICS WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

Go to component -> Navigation circuit, 13 speakers (1 of 9) -> COMPOSITE IMG SIG GND PNK COMPOSITE IMG SIG WIRE

Wiring diagram composite img sig gnd pnk composite img sig (2 of 4)

Wiring diagram composite img sig gnd pnk composite img sig for Infiniti QX80 I (2013-2014) (2 of 4)

Get access

AUX IMG SIG AV CONTROL UNIT (BELOW CENTER OF DASH) BACK BLK WIRE BLU WIRE COMBINATION SWITCH (SPIRAL CABLE) COMPOSITE IMG SIG GND PNK COMPOSITE IMG SIG WIRE DISK EJECT SIG ENTER FUSE 19 FUSE 4 FUSE 5 FUSE 8 FUSE 9 FUSE BLOCK (J/B) GRN WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START LF SND SIG(+) PNK LF SND SIG(-) WIRE LR SND SIG(-) LT GRN WIRE MENU DOWN MENU UP NCA WIRE ORG/ WIRE PNK WIRE PPL PPL AUX IMG GND SHIELD SHIELD PPL LR SND SIG(+) RED WIRE RED/WHT WIRE RF SND SIG(-) RR SND SIG(-) SHIELD SHIELD SHIELD SOURCE STEERING SWITCH STRG SW A PPL STRG SW B STRG SW GND SWITCH GND TEL UP VOICE VOLUME DOWN VOLUME- W/ TELEMATICS WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

Go to component -> Navigation circuit, 15 speakers (1 of 10) -> COMPOSITE IMG SIG GND PNK COMPOSITE IMG SIG WIRE
