Infiniti QX80 I (2013-2014) com im sig gnd Wiring diagrams

This page contains all the electrical diagrams for the component. com im sig gnd, in which he is found in the car Infiniti QX80 I (2013-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram com im sig gnd (1 of 4)

Wiring diagram com im sig gnd for Infiniti QX80 I (2013-2014) (1 of 4)

Get access

ACC PWR SUPP AV COMM(H) AV COMM(L) AV CONTROL UNIT BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/WHT WIRE CAMERA IMG SIG CAN L CAN-H COM IM SIG GND COMBINATION METER COMM COMM CONT COMM DISP COMP IMG COMP IMG SIG COMP IMG SIG GND COMP IMG SYNC SIG COMPUTER COMPUTER DATA DATA LINES DIMMER SIG DISK EJECT SIG FRONT DISPLAY UNIT FUSE 35 FUSE, FUSIBLE LINK, RELAY BOX GRY/BLU WIRE HOT AT ALL TIMES I KEY IDNT SIG IDNT SIG IGNTION SIG LINES SYSTEM LT BLU WIRE LT GRN WIRE MICRO SHIELD MICROPH VCC MICROPHONE SIG MULTI- FUNCTION SWITCH NCA WIRE NOT USED ORG/ WIRE PARKING BRAKE SWITCH PKNG BRAKE SIG PNK WIRE PPL PPL PPL RED WIRE RED/WHT WIRE RED/YEL WIRE REVERSE 12 REVERSE SIG RGB DIG IMG SIG(+) SHIELD SW GND SYN SIG SYSTEM VSS VSS (8-PLSE) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

Go to component -> Navigation circuit, 13 speakers (2 of 9) -> COM IM SIG GND

Wiring diagram com im sig gnd (2 of 4)

Wiring diagram com im sig gnd for Infiniti QX80 I (2013-2014) (2 of 4)

Get access

ACC PWR SUPP ACC RLY CONT AV COMM(H) AV COMM(L) AV CONTROL UNIT BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/WHT WIRE CAMERA IMG SIG CAN L CAN-H CAN-H PNK CAN-L WIRE COM IM SIG GND COMBINATION METER COMM COMM CONT COMM DISP COMP IMG COMP IMG SIG COMP IMG SIG GND COMP IMG SYNC SIG COMPUTER COMPUTER DATA COMPUTER DATA LINES SYSTEM DATA LINES DIMMER SIG DISK EJECT SIG FRONT DISPLAY UNIT FUSE 35 FUSE, FUSIBLE LINK, RELAY BOX GRY/BLU WIRE HOT AT ALL TIMES I KEY IDNT SIG I KY LNK OUTPUT IGNTION SIG LINES SYSTEM LT BLU WIRE LT GRN WIRE MICRO SHIELD MICROPH VCC MICROPHONE SIG MULTI- FUNCTION SWITCH NCA WIRE NOT USED ORG/ WIRE PARKING BRAKE SWITCH PKNG BRAKE SIG PNK WIRE PPL RED WIRE RED/WHT WIRE RED/YEL WIRE REVERSE SIG RGB DIG IMG SIG(+) SHIELD SW GND SYNC SIG SYSTEM VSS VSS (8-PLSE) W/ TELEMATICS W/O TELEMATICS WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

Go to component -> Navigation circuit, 15 speakers (2 of 10) -> COM IM SIG GND
