Infiniti QX80 I (2013-2014) can communication line pnk can communication line Wiring diagram
This page shows the only wiring diagram for the component.can communication line pnk can communication line, which is found in the car Infiniti QX80 I (2013-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram can communication line pnk can communication line (1 of 1)
+IG
BAT (F/L)
BAT FUSE
BATTERY TERMINAL W/ FUSIBLE LINK
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
CAN COMMUNICATION LINE PNK CAN COMMUNICATION LINE WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CRANKING REQUEST
DATA
ECM (ENGINE CONTROL MODULE)
FUSE 10
FUSE 3
FUSE 43
FUSE 6
FUSE 7
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX
FUSIBLE LINK C
FUSIBLE LINK K
GRN WIRE
GRY WIRE
GRY/RED WIRE
H/LP HI
H/LP LO
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION RELAY
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LT GRN WIRE
LT GRN/RED WIRE
NATS ANT AMP
NATS ANTENNA AMPLIFIER
ORG/BLU WIRE
PNK CLK WIRE
PNK WIRE
SECURITY IND
SECURITY IND CONT
STOP LAMP SW 2
UNIFIED METER CONTROL UNIT
YEL WIRE
Go to component -> Immobilizer circuit -> CAN COMMUNICATION LINE PNK CAN COMMUNICATION LINE WIRE
