Tire pressure monitoring circuit for Infiniti QX60 II (2021-2024)
Tire pressure monitoring circuit
BATT PWR SPLY (FUSE)
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FUSE 15
FUSE 29
FUSE 6
FUSE BLOCK (J/B)
HOT AT ALL TIMES
HOT W/ IGNITION RELAY 1 ENERGIZED
MASTER SPEAKER
PPL/BLU WIRE
PPL/GRN WIRE
PPL/TAN WIRE
PPL/WHT WIRE
RED WIRE
TAN WIRE
TIRE PRESSURE IND
TIRE PRESSURE SENSOR
UNIFIED METER CONTROL UNIT
W/ 7 INCH INFORMATION DISPLAY METER
W/ FULL TFT METER
