Seatback power return control circuit for Infiniti QX60 II (2021-2024)
Seatback power return control circuit
BLK WIRE
BLU WIRE
BRN WIRE
DWN
FUSE 55
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOME POSI SENS LH 1 SIG
HOT AT ALL TIMES
ILL
LEFT POWER RETURN MOTOR
LEFT REAR SEATBACK SWITCH
LH MTR DOWN PNK LH MTR HALL - WIRE
LH MTR HALL +
LH MTR UP
LH SEAT BACK SW HOME POSI SENS LH 2 SIG
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
PPL RH SEAT BACK SW
RED WIRE
RH HOME POSI SENS SIG
RH MTR DOWN
RH MTR HALL +
RH MTR UP
RIGHT POWER RETURN MOTOR
RIGHT REAR SEATBACK SWITCH
SEAT BACK POWER RETURN CONTROL UNIT
SENS GND
TAN WIRE
WHT WIRE
YEL WIRE
