Infiniti QX60 II (2021-2024) wireless charger indicator Wiring diagram
This page shows the only wiring diagram for the component.wireless charger indicator, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wireless charger indicator (1 of 1)
ACC PWR SPLY
AUTO ANTI-DAZZLING INSIDE MIRROR
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CHASSIS CONTROL MODULE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONDENSER 1
ELECTRIC INTAKE VALVE TIMING CONTROL MODULE
EPS CONTROL UNIT
FROM FUSE 73 (DIAGRAM 4 OF 8)
FROM FUSIBLE LINK BOX (BATTERY) (DIAGRAM 1 OF 8)
FUSE 10
FUSE 11
FUSE 4
FUSE 5
FUSE 6
FUSE 8
FUSE 81
GREEN IND
GRN WIRE
GRY WIRE
IGNITION COIL 1 (W/ POWER TRANSISTOR)
IGNITION COIL 2 (W/ POWER TRANSISTOR)
IGNITION COIL 3 (W/ POWER TRANSISTOR)
IGNITION COIL 4 (W/ POWER TRANSISTOR)
IGNITION COIL 5 (W/ POWER TRANSISTOR)
IGNITION COIL 6 (W/ POWER TRANSISTOR)
IGNITION RELAY 1
INTELLIGENT REAR VIEW MIRROR
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LOOP WIRE
LT BLU WIRE
LT GRN WIRE
ORG IND WIRE
PNK WIRE
PPL
PPL/BRN WIRE
PPL/GRN WIRE
PPL/TAN WIRE
REAR WINDOW DEFOGGER RELAY
RED WIRE
STEERING ANGLE SENSOR
TAN WIRE
TO FUSE 9 (DIAGRAM 8 OF 8)
TO INVERTER UNIT (DIAGRAM 5 OF 8)
TO LEFT ACCESSORY PRE-WIRE (DIAGRAM 7 OF 8)
TO RIGHT ACCESSORY PRE-WIRE (DIAGRAM 7 OF 8)
TOTAL ILLUMINATION CONTROL UNIT
TRAILER TOW RELAY 2
W/ 7 INCH INFORMATION DISPLAY METER
W/ AUTO ANTI-DAZZLING INSIDE MIRROR
W/ FULL TFT METER
W/ HOMELINK UNIVERSAL TRANSCEIVER
W/ INTELLIGENT REAR VIEW MIRROR
W/O HOMELINK UNIVERSAL TRANSCEIVER
WHT WIRE
WIRELESS CHARGER INDICATOR
WIRELESS CHARGER UNIT
WIRELESS CHG IND (GREEN) SIG
WIRELESS CHG IND (ORANGE) SIG
WIRELESS CHG IND GND
Go to component -> Power distribution circuit (3 of 8) -> WIRELESS CHARGER INDICATOR
