Infiniti QX60 II (2021-2024) wifi ant shield Wiring diagrams

This page contains all the electrical diagrams for the component. wifi ant shield, in which he is found in the car Infiniti QX60 II (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram wifi ant shield (1 of 4)

Wiring diagram wifi ant shield for Infiniti QX60 II (2021-2024) (1 of 4)

Get access

AV CONTROL UNIT (UNDER CENTER CONSOLE) BLK WIRE BLU WIRE BRN WIRE FR SP LH (-) FR SP RH (-) FUSE 25 FUSE BLOCK (J/B) GPS ANT SIG GRY WIRE HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE LVDS M CAN-H M CAN-L PNK WIRE PPL PREAMP SHIELD RED WIRE RIGHT END OF DASH) RIGHT FRONT TWEETER RIGHT LOWER FRONT DOOR SPEAKER RR SP LH (-) SHIELD WHT WIRE WIFI ANT WIFI ANT SHIELD YEL WIRE

Go to component -> Navigation circuit, w/ bose (1 of 6) -> WIFI ANT SHIELD

Wiring diagram wifi ant shield (2 of 4)

Wiring diagram wifi ant shield for Infiniti QX60 II (2021-2024) (2 of 4)

Get access

AV CONTROL UNIT (UNDER CENTER CONSOLE) BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM D - DOUT ETHERNET FR SP LH (-) FR SP RH (-) FUSE 25 FUSE BLOCK (J/B) GPS ANT SIG GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT DOOR SPEAKER LEFT INSTRUMENT PANEL TWEETER LT BLU WIRE LT GRN WIRE LVDS M CAN-H M CAN-L NAVIGATION SYSTEM NAVIGATION SYSTEM (TELEMATICS CIRCUIT) PNK WIRE PPL RED WIRE RIGHT END OF DASH) RR SP LH (-) RR SP RH (-) SHIELD VBUS WHT WIRE WIFI ANT WIFI ANT SHIELD YEL WIRE

Go to component -> Navigation circuit, w/o bose (1 of 5) -> WIFI ANT SHIELD
