Infiniti QX60 II (2021-2024) w/ intelligent cruise control system Wiring diagram
This page shows the only wiring diagram for the component.w/ intelligent cruise control system, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ intelligent cruise control system (1 of 1)
ASCD STEERING SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMBINATION SWITCH (SPIRAL CABLE)
COMPUTER DATA LINES SYSTEM
DOWN
DRIVE MODE SWITCH
GLOVE BOX LAMP)
GRN WIRE
HOT AT ALL TIMES
ICC STEERING SWITCH
ILLUMINATION
ILLUMINATION CONTROL SWITCH
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT REAR SEAT BACK SWITCH
NCA WIRE
ORG/ WIRE
PARKING BRAKE SWITCH
PNK WIRE
PPL/TAN WIRE
PPL/WHT WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT REAR SEAT BACK SWITCH
SMART FET
STEERING COLUMN ASSEMBLY
STEERING SWITCH
STOP/START OFF SWITCH
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
W/ 7 INCH INFORMATION DISPLAY METER
W/ FULL TFT METER
W/ INTELLIGENT CRUISE CONTROL SYSTEM
W/ THIRD ROW POWER RETURN SEATBACK
W/O INTELLIGENT CRUISE CONTROL SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 3) -> W/ INTELLIGENT CRUISE CONTROL SYSTEM
