Infiniti QX60 II (2021-2024) strg sw b Wiring diagrams
This page contains all the electrical diagrams for the component. strg sw b, in which he is found in the car Infiniti QX60 II (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram strg sw b (1 of 2)
AV CONTROL UNIT (UNDER CENTER CONSOLE)
BLK WIRE
BLU WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
D -
DOUT
ETHERNET COMMUNICATION (+)
FRONT AUXILIARY INPUT JACKS
GRN WIRE
GRY WIRE
HEAD UP DISPLAY UNIT
HF/VR MIC 1 INPUT
HF/VR MODE CHANGE
IGN SIG
ILL
LT BLU WIRE
LT GRN WIRE
M CAN-H
M CAN-L
MIC IN - (GND)
NAVIGATION SYSTEM
NAVIGATION SYSTEM (TELEMATICS CIRCUIT)
PNK WIRE
PPL
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/TAN WIRE
RED WIRE
SHIELD
SIG A
STRG SW
STRG SW B
STRG SW GND
TAN WIRE
TCU TEL IN-
TCU TEL SHIELD
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
VBUS
W/ 7 INCH INFORMATION DISPLAY METER W/ FULL TFT METER
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, w/ bose (6 of 6) -> STRG SW B
