Infiniti QX60 II (2021-2024) steering vibration mtr sig gnd Wiring diagram
This page shows the only wiring diagram for the component.steering vibration mtr sig gnd, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering vibration mtr sig gnd (1 of 1)
ADAS CONTROL UNIT 2
ADAS UNIT
BLK WIRE
BRN WIRE
COMPUTER
COMPUTER DATA LINES SYSTEM
DATA LINES
DISTANCE SENSOR
ETHERNET
FRONT CAMERA UNIT (OVERHEAD CENTER CONSOLE)
FUSE 40
FUSE 6
FUSE 9
FUSE BLOCK (J/B)
GRN WIRE
GROUND
HOT W/ ACC RELAY ENERGIZED
HOT W/ IGNITION RELAY 1 ENERGIZED
IGNITION POWER SUPPLY
ITS CAN COMMUNICATION-H
ITS CAN COMMUNICATION-L
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
PPL/LT GRN WIRE
PPL/TAN WIRE
RED WIRE
SHIELD
STEERING ASSIST SW SIG
STEERING ASSIST SWITCH
STEERING VIBRATION MOTOR SIG
STEERING VIBRATION MTR SIG GND
SYSTEM
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Intelligent cruise control circuit (1 of 2) -> STEERING VIBRATION MTR SIG GND
