Infiniti QX60 II (2021-2024) right rear door tweeter lamp Wiring diagram
This page shows the only wiring diagram for the component.right rear door tweeter lamp, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear door tweeter lamp (1 of 1)
BLK WIRE
BRN WIRE
GRN WIRE
GRY WIRE
LEFT DOOR LOCK/UNLOCK SWITCH
LEFT DOOR MIRROR
LEFT FRONT STEP LAMP
LT BLU WIRE
LT GRN WIRE
MOOD LAMP (RIGHT REAR DOOR)
PNK WIRE
PPL
PPL/BLU WIRE
PPL/GRN WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/RED WIRE
RED WIRE
RIGHT DOOR LOCK/UNLOCK SWITCH
RIGHT REAR DOOR PULL LAMP
RIGHT REAR DOOR TWEETER LAMP
RIGHT REAR STEP LAMP
TAN WIRE
W/ INTERIOR AMBIENT LIGHTING
W/O INTERIOR AMBIENT LIGHTING
WELCOME LAMP
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 6) -> RIGHT REAR DOOR TWEETER LAMP
