Infiniti QX60 II (2021-2024) right radar sensor Wiring diagram
This page shows the only wiring diagram for the component.right radar sensor, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right radar sensor (1 of 1)
AFS CONTROL UNIT
AIR BAG DIAGNOSIS SENSOR UNIT
AWD CONTROL UNIT
BLU WIRE
COOLING FAN RELAY
DISTANCE SENSOR
FROM FUSE 4 (DIAGRAM 3 OF 8)
FROM IGNITION RELAY 3 (DIAGRAM 1 OF 8)
FRONT CAMERA UNIT
FUSE 64
FUSE 66
FUSE 67
FUSE 7
FUSE 9
LEFT FRONT SEAT HEATER
LEFT RADAR SENSOR
LEFT SEAT BACK BLOWER
LEFT SEAT CUSHION BLOWER
LEFT SECOND ROW SEAT CUSHION HEATER
LT GRN WIRE
OCCUPANT CLASSIFICATION SYSTEM CONTROL UNIT
PNK WIRE
PPL
PPL/BLU WIRE
PPL/LT GRN WIRE
REAR BLOWER MOTOR RESISTOR
RED WIRE
RIGHT FRONT SEAT HEATER
RIGHT RADAR SENSOR
RIGHT SEAT BACK BLOWER
RIGHT SEAT CUSHION BLOWER
RIGHT SECOND ROW SEAT CUSHION HEATER
TAN WIRE
W/ CLIMATE CONTROLLED SEAT
W/ FRONT HEATED SEATS
W/ SECOND ROW HEATED SEATS
W/O SECOND ROW HEATED SEATS
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (8 of 8) -> RIGHT RADAR SENSOR
