Infiniti QX60 II (2021-2024) right power return motor Wiring diagram
This page shows the only wiring diagram for the component.right power return motor, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right power return motor (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DWN
FUSE 55
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOME POSI SENS LH 1 SIG
HOT AT ALL TIMES
ILL
LEFT POWER RETURN MOTOR
LEFT REAR SEATBACK SWITCH
LH MTR DOWN PNK LH MTR HALL - WIRE
LH MTR HALL +
LH MTR UP
LH SEAT BACK SW HOME POSI SENS LH 2 SIG
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
PPL RH SEAT BACK SW
RED WIRE
RH HOME POSI SENS SIG
RH MTR DOWN
RH MTR HALL +
RH MTR UP
RIGHT POWER RETURN MOTOR
RIGHT REAR SEATBACK SWITCH
SEAT BACK POWER RETURN CONTROL UNIT
SENS GND
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Seatback power return control circuit -> RIGHT POWER RETURN MOTOR
