Infiniti QX60 II (2021-2024) reclining switch Wiring diagram
This page shows the only wiring diagram for the component.reclining switch, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram reclining switch (1 of 1)
BK FD
BLK WIRE
BLU WIRE
BRN WIRE
DN UP
DN UP DN FD FD
FD BK BK FD
FD BK FD BK
FRONT LIFTING SWITCH
FUSE 57
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT GRN WIRE
PNK WIRE
PPL
REAR LIFTING SWITCH
RECLINING SWITCH
RED WIRE
RIGHT FRONT LIFTING MOTOR
RIGHT POWER SEAT SWITCH
RIGHT REAR LIFTING MOTOR
RIGHT RECLINING MOTOR
RIGHT SLIDING MOTOR
SLIDING SWITCH
TAN WIRE
UP DN
UP DN DN
WHT WIRE
Go to component -> Passenger power seat circuit -> RECLINING SWITCH
