Infiniti QX60 II (2021-2024) power window main switch, door mirror switch Wiring diagram
This page shows the only wiring diagram for the component.power window main switch, door mirror switch, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power window main switch, door mirror switch (1 of 1)
BATT POW SUPPLY
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
DOOR SWITCH
DOWN
FUSE 15
FUSE 45
FUSE 49
FUSE 50
FUSE 51
FUSE 52
FUSE BLOCK (J/B)
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY ENERGIZED
LEFT FRONT DOOR LOCK ASSEMBLY
LEFT FRONT POWER WINDOW MOTOR
LF DOOR SWITCH
LIN-COMM
LOGIC
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
POWER WINDOW MAIN SWITCH, DOOR MIRROR SWITCH
PPL
PPL/BLU WIRE
PPL/GRY WIRE
PPL/LT BLU WIRE
PPL/RED WIRE
PPL/WHT WIRE
PPL/YEL WIRE
RED WIRE
RF DOOR SWITCH
RIGHT FRONT DOOR LOCK ASSEMBLY
WHT WIRE
WINDOW LOCK SWITCH
YEL WIRE
Go to component -> Power windows circuit (1 of 2) -> POWER WINDOW MAIN SWITCH, DOOR MIRROR SWITCH
