Infiniti QX60 II (2021-2024) open sw Wiring diagram
This page shows the only wiring diagram for the component.open sw, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram open sw (1 of 1)
AUTO ACCESSORY
AUTO ACCESSORY OPEN SW
BATT POW SUPPLY
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CLOSE
CLOSE SW
COMBINATION METER
COMPUTER DATA LINES SYSTEM
EXTENDED STORAGE FUSE SWITCH
FUSE 15
FUSE 30
FUSE 31
FUSE 46
FUSE 6
FUSE BLOCK (J/B)
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY ENERGIZED
IGN SIG
LIN
LIN-COMM
LT BLU WIRE
LT GRN WIRE
MOONROOF MOTOR ASSEMBLY (CENTER FRONT OF ROOF)
MOONROOF SWITCH
MOONROOF SWITCH ASSEMBLY
MOTOR COMMUNICATION
OPEN SW
PNK WIRE
PPL
PPL/BLU WIRE
PPL/GRN WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/RED WIRE
PPL/TAN WIRE
PPL/WHT WIRE
PPL/YEL WIRE
PUSH SWITCH
RED WIRE
SUNSHADE MOTOR ASSEMBLY
SUNSHADE SWITCH
TILT SW
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
W/ 7 INCH INFORMATION DISPLAY METER
W/ FULL TFT METER
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> OPEN SW
