Infiniti QX60 II (2021-2024) moonroof switch assembly Wiring diagrams
This page contains all the electrical diagrams for the component. moonroof switch assembly, in which he is found in the car Infiniti QX60 II (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram moonroof switch assembly (1 of 3)
AFS CONTROL UNIT
AIR BAG DIAGNOSIS SENSOR UNIT
AROUND VIEW MONITOR CONTROL UNIT
ASCD STEERING SWITCH
AUTO ANTI-DAZZLING INSIDE MIRROR
BLK WIRE
BLU WIRE
CARGO LAMP
COMBINATION METER
COMBINATION SWITCH (SPIRAL CABLE)
DATA LINK CONNECTOR
DISPLAY UNIT
DRIVE MODE SWITCH
ELECTRIC SHIFT CONTROL MODULE
FRONT AUXILIARY INPUT JACKS
FRONT CAMERA UNIT
FRONT ROOM/MAP LAMP ASSEMBLY
GRY WIRE
ICC STEERING SWITCH
ILLUMINATION CONTROL SWITCH
INTEGRAL SWITCH
INTELLIGENT REAR VIEW MIRROR
LEFT VANITY MIRROR LAMP
MOONROOF SWITCH ASSEMBLY
MULTI- FUNCTION SWITCH
NCA WIRE
PADDLE SHIFTER
PARKING BRAKE SWITCH
PUSH BUTTON IGNITION SWITCH
RAIN SENSOR
REAR A/C SWITCH ASSEMBLY
RIGHT VANITY MIRROR LAMP
SHIELD
SONAR CONTROL UNIT
STEERING ANGLE SENSOR
STEERING ASSIST SWITCH
STEERING COLUMN ASSEMBLY
STEERING SWITCHES
STOP/START OFF SWITCH
TCU SHIELD
TELEMATICS SWITCH
TOTAL ILLUMINATION CONTROL UNIT
W/ 7 INCH INFORMATION DISPLAY METER
W/ ACTIVE AFS
W/ FULL TFT METER
W/ HOMELINK UNIVERSAL TRANSCEIVER
W/O HOMELINK UNIVERSAL TRANSCEIVER
WIRELESS CHARGER UNIT
Go to component -> Ground distribution circuit (5 of 6) -> MOONROOF SWITCH ASSEMBLY
Wiring diagram moonroof switch assembly (2 of 3)
BLK WIRE
BLU WIRE
CONSOLE USB CHARGE PORT
ELECTRIC SHIFT SELECTOR
FRONT AUXILIARY INPUT JACKS
FRONT ROOM/ MAP LAMP ASSEMBLY
GRN WIRE
GRY WIRE
INTEGRAL SWITCH
LEFT DOOR LOCK/ UNLOCK SWITCH
LEFT REAR POWER WINDOW SWITCH
LEFT SEAT MEMORY SWITCH
LT BLU WIRE
MOONROOF SWITCH ASSEMBLY
MULTI- FUNCTION SWITCH
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRY WIRE
PPL/RED WIRE
PPL/YEL WIRE
RED WIRE
RIGHT DOOR LOCK/ UNLOCK SWITCH
RIGHT FRONT POWER WINDOW SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT SEAT MEMORY SWITCH
STEERING ASSIST SWITCH
TELEMATICS SWITCH
W/ MEMORY
Go to component -> Instrument illumination circuit (3 of 3) -> MOONROOF SWITCH ASSEMBLY
Wiring diagram moonroof switch assembly (3 of 3)
AUTO ACCESSORY
AUTO ACCESSORY OPEN SW
BATT POW SUPPLY
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CLOSE
CLOSE SW
COMBINATION METER
COMPUTER DATA LINES SYSTEM
EXTENDED STORAGE FUSE SWITCH
FUSE 15
FUSE 30
FUSE 31
FUSE 46
FUSE 6
FUSE BLOCK (J/B)
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY ENERGIZED
IGN SIG
LIN
LIN-COMM
LT BLU WIRE
LT GRN WIRE
MOONROOF MOTOR ASSEMBLY (CENTER FRONT OF ROOF)
MOONROOF SWITCH
MOONROOF SWITCH ASSEMBLY
MOTOR COMMUNICATION
OPEN SW
PNK WIRE
PPL
PPL/BLU WIRE
PPL/GRN WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/RED WIRE
PPL/TAN WIRE
PPL/WHT WIRE
PPL/YEL WIRE
PUSH SWITCH
RED WIRE
SUNSHADE MOTOR ASSEMBLY
SUNSHADE SWITCH
TILT SW
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
W/ 7 INCH INFORMATION DISPLAY METER
W/ FULL TFT METER
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> MOONROOF SWITCH ASSEMBLY
