Infiniti QX60 II (2021-2024) lh rear door sw Wiring diagrams

This page contains all the electrical diagrams for the component. lh rear door sw, in which he is found in the car Infiniti QX60 II (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram lh rear door sw (1 of 2)

Wiring diagram lh rear door sw for Infiniti QX60 II (2021-2024) (1 of 2)

Get access

ACTUATOR BACK DOOR LOCK ASSEMBLY BLK WIRE BLU WIRE BRAKE PEDAL POSITION SWITCH BRN WIRE CLOSE SWITCH CLOSURE MOTOR DOOR AJAR SWITCH DOOR SWITCH DOOR UNLOCK SWITCH GRN WIRE GRY WIRE HALF LATCH SWITCH LEFT FRONT DOOR LOCK ASSEMBLY LEFT FRONT DOOR REQUEST SWITCH LEFT REAR DOOR LOCK ASSEMBLY LH REAR DOOR SW LT BLU WIRE LT GRN WIRE OPEN SWITCH OTHER PNK WIRE PPL PPL/BLK WIRE PPL/BLU WIRE PPL/BRN WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/LT BLU WIRE PPL/PNK WIRE PPL/RED WIRE PPL/TAN WIRE PPL/WHT WIRE RED WIRE RH REAR DOOR SW RIGHT FRONT DOOR LOCK ASSEMBLY RIGHT FRONT DOOR REQUEST SWITCH RIGHT REAR DOOR LOCK ASSEMBLY SECOND ROW SEAT POWER WALK IN CONTROL UNIT STOP LAMP SWITCH TAN WIRE WHT WIRE YEL WIRE

Go to component -> Forced entry circuit (2 of 3) -> LH REAR DOOR SW

Wiring diagram lh rear door sw (2 of 2)

Wiring diagram lh rear door sw for Infiniti QX60 II (2021-2024) (2 of 2)

Get access

Go to component -> Power door locks circuit (2 of 3) -> LH REAR DOOR SW
