Infiniti QX60 II (2021-2024) leveling motor Wiring diagram
This page shows the only wiring diagram for the component.leveling motor, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram leveling motor (1 of 1)
AFS CONTROL UNIT (LEFT SIDE OF DASH)
AMPLIFIER
BATT PWR SPLY
BLK WIRE
BLU WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FRONT HEIGHT SENSOR
FUSE 29
FUSE 6
FUSE 71
FUSE 9
FUSE BLOCK (J/B)
GRN WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY 1 ENERGIZED
HOT W/ IGNITION RELAY ENERGIZED
IGN
IGN SIG
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT FRONT COMBINATION LAMP
LEVELING MOTOR
LT BLU WIRE
PNK WIRE
PPL
PPL/TAN WIRE
PPL/WHT WIRE
PWR
PWR SPLY
REAR HEIGHT SENSOR
RED WIRE
RIGHT FRONT COMBINATION LAMP
SIG
SIG OUT
SWIVEL ACTUATOR GND
SWIVEL ACTUATOR LIN SIG
SWIVELING MOTOR
TAN WIRE
UNIFIED METER CONTROL UNIT
W/ 7 INCH INFORMATION DISPLAY METER
W/ FULL TFT METER
WHT WIRE
Go to component -> Adaptive front lighting circuit -> LEVELING MOTOR
