Infiniti QX60 II (2021-2024) left seat cushion heater Wiring diagrams
This page contains all the electrical diagrams for the component. left seat cushion heater, in which he is found in the car Infiniti QX60 II (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left seat cushion heater (1 of 2)
A/C AUTO AMPLIFIER (LOWER RIGHT SIDE OF DASH)
AUTO ACC
AUTO ACCESSORY
BLK WIRE
BLOWER CTRL
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
FUSE 40
FUSE 66
FUSE 67
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HEAT SENSOR
HEATER
HEATER SEAT LIN
HOT W/ ACCESSORY RELAY ENERGIZED
HOT W/ IGNITION RELAY-3 ENERGIZED
IGN HEAT HVS
INTEGRAL SWITCH (CENTER OF DASH)
LEFT FRONT SEAT BACK HEATER
LEFT FRONT SEAT HEATER
LEFT SEAT BACK BLOWER
LEFT SEAT CUSHION BLOWER
LEFT SEAT CUSHION HEATER
LIN VEH 2
LIN VEHICLE 2
LT GRN WIRE
MAIN
PNK WIRE
PPL/BLU WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT SEAT BACK HEATER
RIGHT FRONT SEAT HEATER
RIGHT SEAT BACK BLOWER
RIGHT SEAT CUSHION BLOWER
RIGHT SEAT CUSHION HEATER
SUB HEATER
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Climate control seats circuit -> LEFT SEAT CUSHION HEATER
Wiring diagram left seat cushion heater (2 of 2)
A/C AUTO AMPLIFIER (LOWER RIGHT SIDE OF DASH)
AUTO ACC
AUTO ACCESSORY
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
FUSE 40
FUSE 66
FUSE 67
FUSE BLOCK (J/B)
GRN WIRE
HEAT SENSOR
HEATER SEAT LIN
HOT W/ ACCESSORY RELAY ENERGIZED
HOT W/ IGNITION RELAY-3 ENERGIZED
INTEGRAL SWITCH (CENTER OF DASH)
LEFT SEAT CUSHION HEATER
LEFT SECOND ROW SEAT BACK HEATER
LEFT SECOND ROW SEAT CUSHION HEATER
LIN VEHICLE 2
LT GRN WIRE
PNK WIRE
PPL/BLU WIRE
REAR A/C SWITCH ASSEMBLY
RED WIRE
RIGHT END OF DASH)
RIGHT SEAT CUSHION HEATER
RIGHT SECOND ROW SEAT BACK HEATER
RIGHT SECOND ROW SEAT CUSHION HEATER
SUB HEATER
TAN WIRE
YEL WIRE
Go to component -> Second row heated seats circuit -> LEFT SEAT CUSHION HEATER
