Infiniti QX60 II (2021-2024) left rear door request switch Wiring diagrams

This page contains all the electrical diagrams for the component. left rear door request switch, in which he is found in the car Infiniti QX60 II (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram left rear door request switch (1 of 3)

Wiring diagram left rear door request switch for Infiniti QX60 II (2021-2024) (1 of 3)

Get access

BLK WIRE BLU WIRE BRN WIRE BUZZER CAN L CAN-H COMMUNICATION H COMMUNICATION L COMPUTER DATA LINES SYSTEM DHS FL DHS FR DHS RL DHS RR ELECTRIC SHIFT CONTROL MODULE FUSE 13 FUSE 15 FUSE 21 FUSE 32 FUSE 44 FUSE 6 FUSE BLOCK (J/B) FUSE DD GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ IGNITION RELAY 1 ENERGIZED I PWR HFM I START SW INSIDE KEY ANTENNA (CONSOLE) INSIDE KEY ANTENNA (LUGGAGE ROOM) INTELLIGENT KEY UNIT (RIGHT END OF DASH) INTELLIGENT KEY WARNING BUZZER LEFT REAR DOOR OUTSIDE KEY ANTENNA LEFT REAR DOOR REQUEST SWITCH LH ANT A LH ANT B LT BLU WIRE OUTSIDE KEY ANTENNA (REAR BUMPER) PNK WIRE POWER PPL PPL/BLU WIRE PPL/BRN WIRE PPL/GRN WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/PNK WIRE PPL/RED WIRE PPL/TAN WIRE PPL/WHT WIRE PPL/YEL WIRE PWR GND 2 REAR ANT A REAR ANT B RED WIRE RH ANT A RH ANT B RIGHT END OF DASH) RIGHT REAR DOOR OUTSIDE KEY ANTENNA RIGHT REAR DOOR REQUEST SWITCH START BACKLIGHT SUPPLY 1 IN TAN WIRE WHT WIRE YEL WIRE

Go to component -> Forced entry circuit (1 of 3) -> LEFT REAR DOOR REQUEST SWITCH

Wiring diagram left rear door request switch (2 of 3)

Wiring diagram left rear door request switch for Infiniti QX60 II (2021-2024) (2 of 3)

Get access

AUTOMATIC BACK DOOR CONTROL UNIT AUTOMATIC BACK DOOR LOCK, CLOSE SWITCH ASSEMBLY AUTOMATIC BACK DOOR WARNING BUZZER BACK DOOR LOCK ASSEMBLY (AJAR SWITCH) BACK DOOR OPENER SWITCH BLK WIRE BLU WIRE BRN WIRE GRY WIRE HANDS FREE SENSOR CONTROL UNIT HIGH MOUNTED STOP LAMP LEFT LICENSE PLATE LAMP LEFT LOWER FRONT DOOR SPEAKER SHIELD LEFT PRE-CRASH SEAT BELT CONTROL UNIT LEFT REAR COMBINATION LAMP (BACK DOOR SIDE) LEFT REAR COMBINATION LAMP (BODY SIDE) LEFT REAR DOOR REQUEST SWITCH LEFT REAR SEAT BACK SWITCH LEFT SECOND ROW SEAT BACK HEATER LEFT SECOND ROW SEAT CUSHION HEATER LEFT SIDE RADAR NCA WIRE PNK WIRE REAR WIPER MOTOR RED WIRE RIGHT LICENSE PLATE LAMP RIGHT REAR COMBINATION LAMP (BACK DOOR SIDE) RIGHT REAR COMBINATION LAMP (BODY SIDE) RIGHT REAR SEAT BACK SWITCH RIGHT SIDE RADAR SEAT BACK POWER RETURN CONTROL UNIT SUBWOOFER SHIELDS TAN WIRE TRAILER BACKUP RELAY TRAILER TOW (PRE-WIRING) TRAILER TOW RELAY 1 TRAILER TOW RELAY 2

Go to component -> Ground distribution circuit (1 of 6) -> LEFT REAR DOOR REQUEST SWITCH
