Infiniti QX60 II (2021-2024) left bsw indicator wiring diagram
This page shows the only wiring diagram for the component.left bsw indicator, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left bsw indicator wiring diagram (1 of 1)
ACCESSORY
BLK WIRE
BLU WIRE
BRN WIRE
CLOSE
CLOSE OPEN MIRROR RH RIGHTWARD/ DOWNWARD
DEFOGGER SYSTEM
DOWN WARD
EC+
GRN WIRE
GROUND
GRY WIRE
IND
LEFT BSW INDICATOR
LEFT DOOR MIRROR
LEFT WARD OPEN
LT BLU WIRE
LT GRN WIRE
MIRROR LH UPWARD
MIRROR RH LEFTWARD
MIRRORS SYSTEM
NAVIGATION SYSTEM
OPEN LEFT WARD
ORG/ WIRE
PASSENGER DOOR MIRROR CONTROL MODULE
PNK HORIZONTAL SENSOR WIRE
PNK WIRE
PPL
PPL LIN
PPL/GRN WIRE
PPL/GRY WIRE
RED WIRE
RIGHT BSW
RIGHT DOOR MIRROR
RIGHT DOWN WARD WARD
RIGHT WARD
SENSOR
TAN WIRE
TURN
UP WARD
VERTICAL SENSOR
W/ HEATED MIRRORS
WHT WIRE
YEL WIRE
Go to component -> Memory mirrors circuit (2 of 2) -> LEFT BSW INDICATOR
