Infiniti QX60 II (2021-2024) gnss ant sig shield gnss ant shield Wiring diagram
This page shows the only wiring diagram for the component.gnss ant sig shield gnss ant shield, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnss ant sig shield gnss ant shield (1 of 1)
AUDIO HU OUT-
AV CONTROL UNIT (UNDER CENTER CONSOLE)
BLK WIRE
BLU WIRE
CAN L
CAN-H
CAN-H PPL CAN-L
CELLULAR ANT SIG SHIELD CELLULAR ANT SHIELD
CHANGE
COMPUTER DATA LINES SYSTEM
D -
DISPLAY UNIT (UPPER CENTER OF DASH)
ECALL SW
FUSE 17
FUSE 25
FUSE BLOCK (J/B)
GNSS ANT SIG SHIELD GNSS ANT SHIELD
GPS ANTENNA
GRN WIRE
HF/VR MIC 1
HF/VR MODE
HOT AT ALL TIMES
INPUT
INTEGRAL SWITCH (CENTER OF DASH)
LED A
LT BLU WIRE
LT GRN WIRE
M CAN-H
M CAN-L
MIC GND
MIC IN - (GND)
MIC OUT SIGNAL
MIC SIG
MIC SIGNAL
MIC VCC
MIC VCC HF/VR MODE CHG
MICROPHONE (IN ROOF CONSOLE)
PNK WIRE
PPL
PPL/BRN WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
RED WIRE
RIGHT END OF DASH)
SHIELD
SHIELD SHIELD
TCU
TCU TEL IN-
TCU TEL SHIELD
TEL ANTENNA
TELEMATICS ANTENNA
TELEMATICS SWITCH (IN OVERHEAD CONSOLE)
VBAT
VBUS
VBUS SHIELD SHIELD
W/O BOSE
WHT WIRE
Go to component -> Telematics circuit -> GNSS ANT SIG SHIELD GNSS ANT SHIELD
