Infiniti QX60 II (2021-2024) fuel level sensor unit, fuel pump shield Wiring diagram
This page shows the only wiring diagram for the component.fuel level sensor unit, fuel pump shield, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuel level sensor unit, fuel pump shield (1 of 1)
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
AWD CONTROL UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CONDENSER 1
DRIVER SEAT CONTROL UNIT
FUEL LEVEL SENSOR UNIT, FUEL PUMP SHIELD
FUEL PUMP CONTROL MODULE (FPCM)
GRY WIRE
IGNITION COIL 1 (W/ POWER TRANSISTOR)
IGNITION COIL 2 (W/ POWER TRANSISTOR)
IGNITION COIL 3 (W/ POWER TRANSISTOR)
IGNITION COIL 4 (W/ POWER TRANSISTOR)
IGNITION COIL 5 (W/ POWER TRANSISTOR)
IGNITION COIL 6 (W/ POWER TRANSISTOR)
LEFT DOOR LOCK/ UNLOCK SWITCH
LEFT DOOR MIRROR
LEFT FRONT DOOR LOCK ASSEMBLY
LEFT FRONT DOOR REQUEST SWITCH
LEFT FRONT POWER WINDOW MOTOR
LEFT FRONT SEAT BELT BUCKLE SWITCH
LEFT FRONT SEAT HEATER
LEFT REAR DOOR LOCK ASSEMBLY
LEFT REAR POWER WINDOW MOTOR
LEFT REAR POWER WINDOW SWITCH (DOOR SWITCH)
LEFT SEAT BACK BLOWER
LEFT SEAT CUSHION BLOWER
LEFT SEAT MEMORY SWITCH
MAIN POWER WINDOW, DOOR MIRROR SWITCH
NCA WIRE
PPL/BLK WIRE
REAR CARGO POWER SOCKET
SHIELD
TRANSFER OIL TEMPERATURE SENSOR
W/ CLIMATE CONTROLLED SEAT
W/ HEATED MIRRORS
W/O EXTENDED INTERIOR AMBIENT LIGHTING
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (2 of 6) -> FUEL LEVEL SENSOR UNIT, FUEL PUMP SHIELD
