Infiniti QX60 II (2021-2024) fuel inj drv gnd 1 Wiring diagram
This page shows the only wiring diagram for the component.fuel inj drv gnd 1, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuel inj drv gnd 1 (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CRANKSHAFT POSITION SENSOR
ENG COOLANT TEMP SENS 2 (BANK 1)
ENG OIL TEMP SENS
EXHAUST CAMSHAFT POSITION SENSOR (BANK 1)
EXHAUST POS SENS
FUEL INJ 1 (HI)
FUEL INJ 1 (LO)
FUEL INJ 2 (HI)
FUEL INJ 2 (LO)
FUEL INJ 3 (HI)
FUEL INJ 3 (LO)
FUEL INJ 4 (HI)
FUEL INJ 4 (LO)
FUEL INJ 5 (HI)
FUEL INJ 5 (LO)
FUEL INJ 6 (HI)
FUEL INJ 6 (LO)
FUEL INJ DRV GND 1
FUEL INJECTOR 1
FUEL INJECTOR 2
FUEL INJECTOR 3
FUEL INJECTOR 4
FUEL INJECTOR 5
FUEL INJECTOR 6
FUEL INJECTOR RELAY 1
FUEL INJECTOR RELAY 2
FUEL RAIL PRESS SENS
FUSE 92
FUSE 94
FUSE, FUSIBLE LINK, RELAY BOX
GRY WIRE
HI PRESS PMP HI
HI PRESS PMP LO
HOT AT ALL TIMES
INCAMOUT 1 ECU OUT
INTAKE AIR TEMPERATURE SENSOR
INTAKE CAMSHAFT POSITION SENSOR (BANK 1)
INTAKE SENS (BANK 1)
KNOCK SENS 1 (-)
LT BLU WIRE
LT GRN WIRE
MASS AIR FLOW SENSOR (ON AIR CLEANER BOX)
PPL
PPL HI PRESS PWR SPLY
PPL SENS GND
RED WIRE
SENS 2 (BANK 1)
SENS 2 (BANK 2)
SENS GND
SENS GND CRANKSHAFT POS SENS CRANKSHAFT POS SENS MASS AIR FLOW SENS
SENS PWR SPLY
SENS PWR SPLY PPL INTAKE AIR TEMP SENS
SHIELD
SHIELD GND
TOP OF TRANSMISSION)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l (1 of 7) -> FUEL INJ DRV GND 1
