Infiniti QX60 II (2021-2024) exhaust gas/outside door detecting sensor Wiring diagram
This page shows the only wiring diagram for the component.exhaust gas/outside door detecting sensor, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram exhaust gas/outside door detecting sensor (1 of 1)
AQS CO SENS
AQS PRE HEAT
AQX NOX SENS
BATT SPLY
BLK WIRE
BLU WIRE
BRN WIRE
EXHAUST GAS/OUTSIDE DOOR DETECTING SENSOR
FAN DUTY
FRONT BLOWER MOTOR
GRN WIRE
GRY WIRE
INTAKE SENSOR
IONIZER UNIT
LEFT SENS
LT GRN WIRE
OUT
PNK WIRE
PPL/BLU WIRE
REAR BLOWER MOTOR
REAR BLOWER MOTOR RESISTOR
REAR IN-VEHICLE SENSOR
RED WIRE
RIGHT END OF DASH)
RIGHT SENS
RR BLWR MTR-
SENS GND
SENS GND (SGND)
SUN
SUNLOAD SENSOR
TAN WIRE
W/O ADVANCED CLIMATE CONTROL SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (2 of 4) -> EXHAUST GAS/OUTSIDE DOOR DETECTING SENSOR
