Infiniti QX60 II (2021-2024) elr lh+ Wiring diagram
This page shows the only wiring diagram for the component.elr lh+, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram elr lh+ (1 of 1)
ACTIVE VENT
AIR BAG
AIR BAG DIAGNOSIS SENSOR UNIT
BLK WIRE
BLU WIRE
BRN WIRE
BUCKLE SW RR LH
CAN-H PNK CAN-L WIRE
COMMON GND FOR SBR
COMPUTER DATA LINES SYSTEM
CONN LOCK DETECT A
CONN LOCK DETECT B
CRASH ZONE (+)
DRIVER'S SEAT
ELR LH+
FAR LH-
FRONT CENTER AIR BAG MODULE
GRN WIRE
GRY WIRE
IGN PPL TELLTALE LAMP ON
IND OFF
IND ON
INF CURTAIN RR LH-
INFLATOR DR+ PNK WIRE
INTEGRAL SWITCH
KNEE LH-
KNEE RH (+)
LEFT FRONT SIDE AIR BAG MODULE
LEFT FRONT SIDE AIR BAG SATELLITE SENSOR
LEFT REAR SEAT BELT PRE-TENSIONER
LEFT REAR SIDE AIR BAG MODULE
LEFT REAR SIDE AIR BAG SATELLITE SENSOR
LEFT SIDE CURTAIN AIR BAG MODULE
LH -
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
PPL/BLK WIRE
RED WIRE
RP LH+
RR SATELLITE
RR SATELLITE SENS LH+ PNK BUCKLE SW RR CTR WIRE
RR SATELLITE SENS LH-
RS INF LH+ PPL
RS INF LH-
SENS LH (-)
SHIELD
SIDE INF LH-
SIDE SENS
SIDE SENS LH+ PPL SIDE SENS LH-
TAN WIRE
TELLTALE LAMP OFF
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (1 of 4) -> ELR LH+
