Infiniti QX60 II (2021-2024) electronic controlled engine mount control solenoid valve Wiring diagram
This page shows the only wiring diagram for the component.electronic controlled engine mount control solenoid valve, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electronic controlled engine mount control solenoid valve (1 of 1)
ACTIVE GRILLE SHUTTER
BATTERY
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONDENSER 1
ELECTRONIC CONTROLLED ENGINE MOUNT CONTROL SOLENOID VALVE
EVAP CANISTER VENT CONTROL VALVE
F/PUMP-
FPC
FPCCK
FUEL PUMP CONTROL MODULE (FPCM)
GENERATOR
GRN WIRE
GROUND
GRY WIRE
IGN
IGNITION
IGNITION COIL 1 (W/ POWER TRANSISTOR)
IGNITION COIL 2 (W/ POWER TRANSISTOR)
IGNITION COIL 3 (W/ POWER TRANSISTOR)
IGNITION COIL 4 (W/ POWER TRANSISTOR)
IGNITION COIL 5 (W/ POWER TRANSISTOR)
IGNITION COIL 6 (W/ POWER TRANSISTOR)
LIN
LOOP WIRE
LT BLU WIRE
LT GRN WIRE
MALFUNCTION INDICATOR LAMP (MIL)
NCA WIRE
PLUG
PNK WIRE
PPL
PPL/BRN WIRE
PPL/GRY WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/TAN WIRE
PPL/YEL WIRE
RED WIRE
SHIELD
SPARK
TAN WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
VIAS CONTROL SOLENOID VALVE 1
VIAS CONTROL SOLENOID VALVE 2
W/ 7 INCH INFORMATION DISPLAY METER
W/ FULL TFT METER
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l (6 of 7) -> ELECTRONIC CONTROLLED ENGINE MOUNT CONTROL SOLENOID VALVE
