Infiniti QX60 II (2021-2024) can-h Wiring diagrams

ACTIVE GRILLE SHUTTER BLK WIRE BLU WIRE CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM ECM (TOP OF TRANSMISSION) FUSE 6 FUSE 83 FUSE BLOCK (J/B) GRY WIRE HOT W/ ECM RELAY ENERGIZED HOT W/ IGNITION RELAY 1 ENERGIZED IGN IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LIN LT BLU WIRE PPL/TAN WIRE RED WIRE TAN WIRE UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) W/ 7 INCH INFORMATION DISPLAY METER W/ FULL TFT METER YEL WIRE

BATT PWR SPLY (FUSE) BCM (BODY CONTROL MODULE) (LEFT SIDE OF DASH) BELT IND BLK WIRE BLU WIRE BRAKE FLUID LEVEL SWITCH BRAKE IND BRN WIRE BUZZER CAN L CAN-H COMBINATION METER COMBINATION SW INPUT 1 COMBINATION SW INPUT 2 COMBINATION SW INPUT 2 PPL COMBINATION SW INPUT 1 COMBINATION SW INPUT 3 COMBINATION SW INPUT 4 COMBINATION SW INPUT 5 COMBINATION SW INPUT 6 COMBINATION SW OUTPUT 1 COMBINATION SW OUTPUT 2 COMBINATION SW OUTPUT 3 COMBINATION SW OUTPUT 4 COMBINATION SW OUTPUT 4 PNK COMBINATION SW OUTPUT 3 WIRE COMBINATION SW OUTPUT 5 COMBINATION SW OUTPUT 6 COMBINATION SWITCH (LIGHTING, TURN SIGNAL SWITCH) COMPUTER DATA LINES SYSTEM FUSE 15 FUSE 29 FUSE 6 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY 1 ENERGIZED INTELLIGENT KEY UNIT INTELLIGENT KEY WARNING BUZZER LEFT FRONT DOOR LOCK ASSEMBLY LEFT FRONT SEAT BELT BUCKLE SWITCH LF DOOR SW LF SEAT BELT BUCKLE SW LT BLU WIRE LT GRN WIRE MASTER SPEAKER PASSIVE RESTRAINTS SYSTEM PNK WIRE PPL PPL/BLU WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/LT BLU WIRE PPL/RED WIRE PPL/TAN WIRE PPL/WHT WIRE RED WIRE RIGHT END OF DASH) STEERING COLUMN ASSEMBLY TAN WIRE UNIFIED METER CONTROL UNIT W/ 7 INCH INFORMATION DISPLAY METER W/ FULL TFT METER WHT WIRE YEL WIRE

ACCESSORY PWR SUPPLY ADAS CONTROL UNIT 2 (UNDER LEFT CENTER OF DASH) AUTOMATIC BRAKE HOLD SW AUTOMATIC BRAKE HOLD SWITCH AUTOMATIC BRAKE HOLD SWITCH IND BATT PWR SUPPLY BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CAN-L AUTOMATIC BRAKE HOLD SW IND CHASSIS CONTROL MODULE (LEFT END OF DASH) COMBINATION METER COMPUTER DATA LINES SYSTEM DISPLAY DISTANCE SENSOR DOWN SWITCH DRIVE MODE SWITCH DRV MODE SW (ECO) DRV MODE SW (SPORT) EXTENDED STORAGE FUSE SW FRONT CAMERA UNIT (OVERHEAD CENTER CONSOLE) FUSE 11 FUSE 20 FUSE 30 FUSE 40 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY RELAY ENERGIZED IC CAN H IC CAN L LT BLU WIRE PARKING BAKE SWITCH PNK WIRE PPL PPL/BRN WIRE PPL/GRN WIRE PPL/TAN WIRE RED WIRE STEERING ANGLE SENSOR (UPPER STEERING COLUMN) UNIFIED METER CONTROL UNIT (W/ INFORMATION UP SWITCH W/ 7 INCH INFORMATION DISPLAY METER W/ FULL TFT METER WHT WIRE YEL WIRE

A/C AUTO AMPLIFIER (LOWER RIGHT SIDE OF DASH) AUTO ACC AUTO ACCESSORY BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM FUSE 40 FUSE 66 FUSE 67 FUSE BLOCK (J/B) GRN WIRE HEAT SENSOR HEATER HEATER SEAT LIN HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ IGNITION RELAY-3 ENERGIZED INTEGRAL SWITCH (CENTER OF DASH) LEFT FRONT SEAT BACK HEATER LEFT SEAT CUSHION HEATER LEFT FRONT SEAT HEATER LIN VEH 2 LIN VEHICLE 2 LT GRN WIRE MAIN PNK WIRE PPL/BLU WIRE RED WIRE RIGHT END OF DASH) RIGHT FRONT SEAT BACK HEATER RIGHT FRONT SEAT HEATER RIGHT SEAT CUSHION HEATER SUB HEATER TAN WIRE WHT WIRE

A/C AUTO AMPLIFIER AUTO ACC BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM FUSE 40 FUSE 62 FUSE BLOCK (J/B) HEATED STEERING WHEEL HEATED STEERING WHEEL RELAY HEATED STEERING WHEEL RELAY, BACKUP LAMP RELAY HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ IGNITION RELAY-2 ENERGIZED INTEGRAL SWITCH (HEATED STEERING WHEEL SWITCH) LIN VEH 2 LIN VEHICLE 2 LT GRN WIRE PNK AUTO ACC WIRE PNK WIRE RED WIRE RIGHT END OF DASH) STEERING COLUMN ASSEMBLY STRG HEATER RLY CTRL TAN WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM DOWN DRIVER SEAT CONTROL UNIT FUSE 54 FUSE 57 FUSE BLOCK (J/B) GRY WIRE HALL EFFECT SENS + (LUMBAR X) HALL EFFECT SENS + (LUMBAR Y) HOT AT ALL TIMES LEFT LUMBAR SUPPORT MOTOR X LEFT LUMBAR SUPPORT MOTOR Y LEFT SEAT MESSAGE SWITCH LT BLU WIRE LUMBAR X MTR (DOWNWARD) LUMBAR X MTR (UPWARD) LUMBAR Y MTR (DOWNWARD) LUMBAR Y MTR (UPWARD) MASSAGE SW MASSAGE SW GND PASSENGER SEAT CONTROL UNIT PPL RED WIRE RIGHT LUMBAR SUPPORT MOTOR X RIGHT LUMBAR SUPPORT MOTOR Y RIGHT SEAT MESSAGE SWITCH SENS GND 2 YEL WIRE

ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) AUTOMATIC BRAKE HOLD SWITCH AUTOMATIC BRAKE HOLD SWITCH IND BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM E-PARK IND (RED) WIRE E-PARK WARNING IND (YELLOW) ELECTRONIC SUSPENSION SYSTEM FUSE 20 FUSE 32 FUSE 6 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX FUSIBLE LINK T GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ IGNITION RELAY 1 ENERGIZED IGN SIG IGNITION SWITCH ON POWER SUPPLY ILL LEFT PARKING BRAKE ACTUATOR LT BLU WIRE MOTOR LH (+) MOTOR RH (+) MOTOR RH (-) MOTOR LH (-) PARKING BRAKE SWITCH (ON PARKING BRAKE PEDAL ASSEMBLY) PARKING BRAKE SWITCH IND PARKING BRAKE SWITCH INDICATOR PARKING BRAKE SWITCH INPUT 1 PARKING BRAKE SWITCH INPUT 2 PARKING BRAKE SWITCH OUTPUT 1 PARKING BRAKE SWITCH OUTPUT 2 PNK WIRE PPL PPL/TAN WIRE RED WIRE RIGHT PARKING BRAKE ACTUATOR TAN WIRE UNIFIED METER CONTROL UNIT VALVE POWER SUPPLY W/ 7 INFORMATION DISPLAY METER W/ FULL TFT METER WHT WIRE YEL WIRE

A/C AUTO AMPLIFIER (LOWER RIGHT SIDE OF DASH) AUTO ACC AUTO ACCESSORY BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM FUSE 40 FUSE 66 FUSE 67 FUSE BLOCK (J/B) GRN WIRE HEAT SENSOR HEATER SEAT LIN HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ IGNITION RELAY-3 ENERGIZED INTEGRAL SWITCH (CENTER OF DASH) LEFT SEAT CUSHION HEATER LEFT SECOND ROW SEAT BACK HEATER LEFT SECOND ROW SEAT CUSHION HEATER LIN VEHICLE 2 LT GRN WIRE PNK WIRE PPL/BLU WIRE REAR A/C SWITCH ASSEMBLY RED WIRE RIGHT END OF DASH) RIGHT SEAT CUSHION HEATER RIGHT SECOND ROW SEAT BACK HEATER RIGHT SECOND ROW SEAT CUSHION HEATER SUB HEATER TAN WIRE YEL WIRE

BAT PWR SPLY BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM D POS IND D POS IND PNK ELECTRIC SHIFT SENS GND 2 WIRE ELECTRIC SHIFT CONTROL MODULE (UNDER CENTER CONSOLE) ELECTRIC SHIFT CONTROL SYSTEM IND ELECTRIC SHIFT SELECTOR ELECTRIC SHIFT SENS 1 ELECTRIC SHIFT SENS 5 ELECTRIC SHIFT SENS 2 ELECTRIC SHIFT SENS 3 ELECTRIC SHIFT SENS 4 ELECTRIC SHIFT SENS 5 ELECTRIC SHIFT SENS 6 ELECTRIC SHIFT SENS 7 ELECTRIC SHIFT SENS 7 ELECTRIC SHIFT SENS PWR SPLY 2 ELECTRIC SHIFT SENS 8 ELECTRIC SHIFT SENS GND 1 ELECTRIC SHIFT SENS GND 2 ELECTRIC SHIFT SENS PWR SPLY ELECTRIC SHIFT SENS PWR SPLY 1 ELECTRIC SHIFT SENS PWR SPLY 1 ELECTRIC SHIFT SENS 1 FUSE 21 FUSE 40 FUSE 44 FUSE 6 FUSE 73 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ IGNITION RELAY 1 ENERGIZED HOT W/ IGNITION RELAY ENERGIZED IGN SIG IGNITION SW 1 IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LT GRN WIRE M POS IND N POS IND P POS IND P POS SW 1 P POS SW 2 P POS SW 2 PNK M POS IND WIRE PNK ELECTRIC SHIFT SENS PWR SPLY 2 ELECTRIC SHIFT SENS 2 WIRE PNK WIRE PPL PPL/BLU WIRE PPL/GRN WIRE PPL/PNK WIRE PPL/RED WIRE PPL/TAN WIRE PWR GND 1 PWR GND 2 PWR SPLY 1 IN PWR SPLY 2 R POS IND R POS IND PPL N POS IND RED WIRE STOP LAMP SW 2 STOP LAMP SWITCH TAN WIRE UNIFIED METER CONTROL UNIT W/ 7 INFORMATION DISPLAY METER W/ FULL TFT METER WHT WIRE YEL WIRE

BATT PWR SPLY (FUSE) BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM FUSE 15 FUSE 29 FUSE 6 FUSE BLOCK (J/B) HOT AT ALL TIMES HOT W/ IGNITION RELAY 1 ENERGIZED MASTER SPEAKER PPL/BLU WIRE PPL/GRN WIRE PPL/TAN WIRE PPL/WHT WIRE RED WIRE TAN WIRE TIRE PRESSURE IND TIRE PRESSURE SENSOR UNIFIED METER CONTROL UNIT W/ 7 INCH INFORMATION DISPLAY METER W/ FULL TFT METER
