Infiniti QX60 II (2021-2024) cam shield Wiring diagram
This page shows the only wiring diagram for the component.cam shield, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cam shield (1 of 1)
BATTERY
BLK WIRE
BLU WIRE
BRN WIRE
CAM SHIELD
CAN L
CAN-H
CASE TEMP
CRANK SIGNAL
ELECTRIC INTAKE VALVE TIMING CONTROL ACTUATOR (BANK 1)
ELECTRIC INTAKE VALVE TIMING CONTROL ACTUATOR (BANK 2)
ELECTRIC INTAKE VALVE TIMING CONTROL MODULE
ELECTRIC INTAKE VALVE TIMING CONTROL MOTOR (BANK 1)
ELECTRIC INTAKE VALVE TIMING CONTROL MOTOR (BANK 2)
ELECTRIC INTAKE VALVE TIMING CONTROL POSITION SENSOR (BANK 1)
ELECTRIC INTAKE VALVE TIMING CONTROL POSITION SENSOR (BANK 2)
FUSE, FUSIBLE LINK, RELAY BOX
FUSIBLE LINK I
FUSIBLE LINK K
GRN WIRE
GROUND
GRY WIRE
HIGH PRESSURE FUEL PUMP
HOT AT ALL TIMES
IGNITION
KNOCK SENSOR BANK 1
LT BLU WIRE
LT GRN WIRE
PNK WIRE
RED WIRE
SHIELD
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l (2 of 7) -> CAM SHIELD
