Infiniti QX60 II (2021-2024) batt saver Wiring diagram
This page shows the only wiring diagram for the component.batt saver, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram batt saver (1 of 1)
ACCESSORY
BATT SAVER
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
FROM A/C AUTO AMP (DIAGRAM 6 OF 8)
FROM FUSE 43 (DIAGRAM 6 OF 8)
FROM FUSE BLOCK (J/B) (DIAGRAM 2 OF 8)
FROM INTEGRAL SWITCH (DIAGRAM 6 OF 8)
FUSE 31
FUSE 46
FUSE 49
FUSE 50
FUSE 51
FUSE BLOCK (J/B) (LEFT END OF DASH)
GRN WIRE
HORN SW
HORNS SYSTEM
IGN
LEFT ACCESSORY PRE-WIRE
LEFT FRONT DOOR LOCK ASSEMBLY (DOOR SWITCH)
LEFT REAR POWER WINDOW MOTOR
LH FR DOOR SW
LT BLU WIRE
LT GRN WIRE
MOONROOF MOTOR ASSEMBLY
PNK WIRE
PPL
PPL/LT BLU WIRE
PPL/RED WIRE
PPL/YEL WIRE
RED WIRE
RIGHT ACCESSORY PRE-WIRE
RIGHT END OF DASH)
RIGHT FRONT POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW MOTOR
ROOM LAMP
SUNSHADE MOTOR ASSEMBLY
TAN WIRE
THRU SIG
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (7 of 8) -> BATT SAVER
