Infiniti QX60 II (2021-2024) backup lamp relay ctrl Wiring diagram
This page shows the only wiring diagram for the component.backup lamp relay ctrl, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backup lamp relay ctrl (1 of 1)
BACK DOOR OPENER SW
BACKUP LAMP RELAY CTRL
BATT PWR SPLY (FUSE)
BATT PWR SPLY (REAR DOOR LOCK ACTUATOR)
BATT PWR SPLY (REAR WIPER)
BATT PWR SPLY (STOP LAMP)
BATT PWR SPLY (TURN SIG LAMP)
BCM (BODY CONTROL MODULE) (LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
DOOR LOCKS, ANTI-THEFT SYSTEMS
DOOR SWITCH (BACK DOOR)
DOOR SWITCH (FRONT LH)
DOOR SWITCH (FRONT RH)
DOOR SWITCH (REAR LH)
DOOR SWITCH (REAR RH)
FRONT DOOR LH UNLOCK BATT PWR SPLY (FRONT DOOR LOCK ACTUATOR)
FRONT DOOR RH UNLOCK
FRONT-REAR DOORS LH LOCK
FUSE 12
FUSE 14
FUSE 15
FUSE 21
FUSE 53
FUSE 56
FUSE BLOCK (J/B)
GRN WIRE
HOT AT ALL TIMES
IGN RELAY-1 CTRL
INTERIOR ROOM LAMP CONTROL
LIN COMM (HANDS FREE SENS)
LOCK FUEL LID
LT BLU WIRE
LT GRN WIRE
O PWM ROOM LAMP 3
O PWM ROOM LAMP 5
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
PPL/BLU WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/LT GRN WIRE
PPL/PNK WIRE
PPL/RED WIRE
PPL/WHT WIRE
PPL/YEL WIRE
PUDDLE LAMP
REAR DOORS RH LOCK
REAR DOORS UNLOCK
REAR WIPER MOTOR
REAR WIPER STOP POSITION
RED WIRE
ROOM LAMP 2
STARTER CUT RELAY CTRL
STARTING/CHARGING SYSTEM
STOP LAMP LH OUTPUT
STOP LAMP RH OUTPUT
STOP LAMP SWITCH 1
STOP LAMP SWITCH 2
TAN WIRE
TRAILER DI LEFT
TRAILER DI RIGHT
TRUNK, TAILGATE, FUEL DOORS SYSTEM
TURN SIG RH OUTPUT (FRONT)
TURN SIGN LH OUTPUT (FRONT)
TURN SIGNAL LH OUTPUT (REAR)
TURN SIGNAL RH OUTPUT (REAR)
UNLOCK FUEL LID
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Body control modules circuit (2 of 2) -> BACKUP LAMP RELAY CTRL
