Infiniti QX60 II (2021-2024) automatic back door control module Wiring diagrams
This page contains all the electrical diagrams for the component. automatic back door control module, in which he is found in the car Infiniti QX60 II (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram automatic back door control module (1 of 2)
A/C AUTO AMP
AFS CONTROL UNIT (W/ ACTIVE AFS)
AIR BAG DIAGNOSIS SENSOR UNIT
AUTOMATIC BACK DOOR CONTROL MODULE
BLU WIRE
CAN L
CAN-H
CAN-H PNK CAN-L WIRE
DRIVER SEAT CONTROL UNIT
INTELLIGENT KEY UNIT
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT PRE-CRASH SEAT BELT CONTROL UNIT
PNK WIRE
PPL/BLU WIRE
PPL/RED WIRE
RED WIRE
RIGHT END OF DASH)
TOTAL ILLUMINATION CONTROL UNIT
Go to component -> Computer data lines circuit (6 of 6) -> AUTOMATIC BACK DOOR CONTROL MODULE
Wiring diagram automatic back door control module (2 of 2)
ANTI- DAZZLING INSIDE MIRROR
AUDIO SPEAKER AMP
AUTOMATIC BACK DOOR CONTROL MODULE
AUTOMATIC DRIVE POSITIONER CONTROL UNIT
AV CONTROL UNIT
BCM (BODY CONTROL MODULE)
BLU WIRE
BOSE SPEAKER AMP
BRN WIRE
COMBINATION METER
DISPLAY UNIT
DRIVER SEAT CONTROL UNIT
EXTENDED STORAGE SWITCH
FROM ACCESSORY RELAY (DIAGRAM 6 OF 8)
FROM FUSIBLE LINK BOX (BATTERY) (DIAGRAM 1 OF 8)
FRONT AUXILIARY INPUT JACKS
FUSE 12
FUSE 14
FUSE 15
FUSE 21
FUSE 25
FUSE 26
FUSE 27
FUSE 28
FUSE 29
FUSE 30
FUSE 53
FUSE 54
FUSE 55
FUSE 56
FUSE 57
FUSE 58
FUSE AA
FUSE DD
GRN WIRE
HANDS FREE SENSOR CONTROL UNIT
LEFT SEAT MEMORY SWITCH
LT GRN WIRE
PASSENGER SEAT CONTROL UNIT
PNK PNK WIRE
PNK WIRE
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/PNK WIRE
PPL/RED WIRE
PPL/WHT WIRE
PPL/YEL WIRE
RED WIRE
RIGHT LUMBAR SUPPORT SWITCH
RIGHT POWER SEAT SWITCH
RIGHT SEAT MEMORY SWITCH
SEAT BACK POWER RETURN CONTROL UNIT
SECOND ROW SEAT POWER WALK IN CONTROL UNIT
STOP LAMP SWITCH
TAN WIRE
TO IGNITION RELAY-2 (DIAGRAM 5 OF 8)
TO RIGHT ACCESSORY PRE-WIRE (DIAGRAM 7 OF 8)
W/ 2 WAY LUMBAR SUPPORT SYSTEM
W/ 7 INCH INFORMATION DISPLAY METER
W/ FULL TFT METER
W/O BOSE
W/O PASSENGER MEMORY SEAT
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 8) -> AUTOMATIC BACK DOOR CONTROL MODULE
