Infiniti QX60 II (2021-2024) auto hold brake ind Wiring diagram
This page shows the only wiring diagram for the component.auto hold brake ind, which is found in the car Infiniti QX60 II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto hold brake ind (1 of 1)
ABS IND.
AEB OFF IND
AIR BAG IND
AUTO HOLD BRAKE IND
BELT IND
BLK WIRE
BLU WIRE
BRAKE IND
BRN WIRE
BSW WARNING IND
BUZZER
CHARGE IND
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DOWN
E-PARK IND (RED) WIRE
E-PARK WARNING (YELLOW) IND
ELECTRIC SHIFT CONTROL SYSTEM IND
EPS IND
FCW WARNING IND
FUEL GAUGE
FUEL LEVEL SENSOR UNIT, FUEL PUMP
FUSE 15
FUSE 29
FUSE 40
FUSE 6
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HANDS OFF WARNING IND
HI BEAM (BLUE) IND
HIGH BEAM ASSIST (GREEN) IND
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY ENERGIZED
HOT W/ IGNITION RELAY 1 ENERGIZED
ILLUMINATION
ILLUMINATION CONTROL SWITCH
LDW WARNING IND
LEFT TURN IND
LIGHT (GREEN) IND
LOW FUEL IND
LT BLU WIRE
LT GRN WIRE
MALFUNCTION IND LAMP (MIL)
MASTER SPEAKER
MASTER WARNING IND (RED/YELLOW) WIRE
METER ILLUMINATION IND
OIL PRESSURE IND
PILOT IND
PNK WIRE
PPL
PPL/BLU WIRE
PPL/GRN WIRE
PPL/RED WIRE
PPL/TAN WIRE
PPL/WHT WIRE
REAR AEB OFF IND
RED WIRE
RIGHT TURN IND
SEATS SYSTEM
SHIELD
SLIP IND
SOUND SYSTEMS
SPEEDOMETER
STOP/START IND
TACHOMETER
TAN WIRE
TIRE PRESSURE IND
UNIFIED METER CONTROL UNIT
VDC OFF IND
W/ 7 INCH INFORMATION DISPLAY METER
W/ FULL TFT METER
WATER TEMPERATURE GAUGE
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 3) -> AUTO HOLD BRAKE IND
