Infiniti QX60 I facelift (2016-2021) Computer data lines circuit, hybrid w/ icc

ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) APPROACHING VEHICLE SOUND FOR PEDESTRIANS (VSP) CONTROL UNIT BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CAN-H PNK CAN-L WIRE CPU CAN-H DATA LINK CONNECTOR ECM (LEFT SIDE OF ENGINE COMPT) FUSE 25 FUSE 30 FUSE 31 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HEV CAN-H HEV CAN-L HOT AT ALL TIMES HOT W/ IGNITION RELAY-2 ENERGIZED HPCM IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) K LINE LT BLU WIRE LT GRN WIRE OCCUPANT CLASSIFICATION SYSTEM CONTROL UNIT PNK WIRE POWER STEERING CONTROL MODULE SHIELD STEERING ANGLE SENSOR (ON STEERING COLUMN) TAN WIRE TCU (IF EQUIPPED) (UNDER CENTER CONSOLE) WHT WIRE

AV CONTROL UNIT BLK WIRE BLU WIRE BOSE SPEAKER AMPLIFIER CAN L CAN-H CAN-H PNK CAN-L WIRE COMBINATION METER DISPLAY CONTROL UNIT GRN WIRE LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MULTI- FUNCTION SWITCH PNK WIRE SHIELD TAN WIRE UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) VIDEO DISTRIBUTOR (UNDER CENTER CONSOLE) W/ SURROUND W/O SURROUND WHT WIRE YEL WIRE

A/C AUTO AMPLIFIER (LOWER CENTER OF DASH) AIR BAG DIAGNOSIS SENSOR UNIT AROUND VIEW MONITOR CONTROL UNIT BATTERY BLK WIRE BLU WIRE CAN - GND CAN GATEWAY CAN L CAN-H GRN WIRE GRY WIRE HEV CAN-H HEV CAN-L IGNITION LI-ION BATTERY CONTROLLER LI-ION BATTERY M CAN GND PNK WIRE RED WIRE SHIELD TAN WIRE TCM (TRANSMISSION CONTROL MODULE) TRACTION MOTOR INVERTER WHT WIRE

ACCELERATOR PEDAL ACTUATOR/ ACCELERATOR PEDAL POSITION SENSOR ADAS CONTROL UNIT (RIGHT REAR OF STORAGE BOX) AUTOMATIC BACK DOOR CONTROL MODULE AWD CONTROL UNIT (IF EQUIPPED) (LEFT REAR OF STORAGE BOX) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CAN-L SHIELD CAN SHIELD DRIVER ASSISTANCE BUZZER CONTROL MODULE DRIVER SEAT CONTROL UNIT DRIVER SIDE PRE-CRASH SEAT BELT CONTROL UNIT GRY WIRE ICC SENSOR (BEHIND RIGHT SIDE OF FRONT BUMPER) ITS CAN-H ITS CAN-L LANE CAMERA UNIT LEFT SIDE RADAR PNK CAN-H WIRE RED WIRE RIGHT SIDE RADAR SHIELD SONAR CONTROL UNIT WHT WIRE YEL WIRE
