Computer data lines circuit, except hybrid w/o can gateway for Infiniti QX60 I facelift (2016-2021)

A/C AUTO AMPLIFIER (LOWER CENTER OF DASH) ABS ACTUATOR, ELECTRIC UNIT (CONTROL MODULE) AIR BAG DIAGNOSIS SENSOR UNIT (UNDER CENTER CONSOLE) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CAN-H PNK CAN-L WIRE COMBINATION METER CPU CAN-H DATA LINK CONNECTOR DRIVER SEAT CONTROL UNIT ECM (LEFT SIDE OF ENGINE COMPT) FUSE 25 FUSE 30 FUSE BLOCK (J/B) GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY-2 ENERGIZED IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) K LINE LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L OCCUPANT CLASSIFICATION SYSTEM CONTROL UNIT PNK CAN-L WIRE PNK WIRE POWER STEERING CONTROL MODULE (LOWER RIGHT REAR OF ENGINE COMPT) RED WIRE STEERING ANGLE SENSOR (ON STEERING COLUMN) TAN WIRE TCM (TRANSMISSION CONTROL MODULE) (LEFT FRONT OF ENGINE COMPT) UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) WHT WIRE

ACCELERATOR PEDAL ACTUATOR (ABOVE ACCELERATOR PEDAL) AROUND VIEW MONITOR CONTROL UNIT BLK WIRE BLU WIRE CAN L CAN-H DRIVER ASSISTANCE BUZZER CONTROL MODULE GRY WIRE ICC SENSOR (IF EQUIPPED) ITS CAN-H ITS CAN-L LEFT SIDE RADAR LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MULTI- FUNCTION SWITCH PNK WIRE RIGHT SIDE RADAR SHIELD SONAR CONTROL UNIT (IF EQUIPPED) (LEFT SIDE OF DASH) TAN WIRE V CAN-H V CAN-L VIDEO DISTRIBUTOR WHT WIRE YEL WIRE

ADAS CONTROL UNIT (IF EQUIPPED) (RIGHT REAR OF STORAGE BOX) AUTOMATIC BACK DOOR CONTROL MODULE AV CONTROL UNIT AWD CONTROL UNIT (IF EQUIPPED) (LEFT REAR OF STORAGE BOX) BCM (BODY CONTROL MODULE) (BEHIND INSTRUMENT CLUSTER) BLK WIRE BLK/YEL WIRE BLU WIRE BOSE SPEAKER AMPLIFIER (UNDER CENTER OF REAR SEATS) CAN L CAN-H DISPLAY CONTROL UNIT GRY WIRE IC CAN H IC CAN L ITS CAN-H ITS CAN-L LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L PNK CAN-L WIRE PNK WIRE SHIELD W/O CENTER POINT AUDIO W/ CENTER POINT AUDIO WHT WIRE YEL WIRE
