Infiniti QX60 I facelift (2016-2021) w/o intelligent cruise control Wiring diagram
This page shows the only wiring diagram for the component.w/o intelligent cruise control, which is found in the car Infiniti QX60 I facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o intelligent cruise control (1 of 1)
ASCD STEERING SWITCH
BLK WIRE
BRN WIRE
COMBINATION SWITCH (SPIRAL CABLE)
DRIVE MODE SELECT SWITCH
DRIVER SEAT CLIMATE CONTROL LED SEAT SWITCH
EXCEPT HYBRID
FRONT ROOM/ MAP LAMP ASSEMBLY
ICC STEERING SWITCH
LEFT FRONT HEATED SEAT SWITCH
MULTI- FUNCTION SWITCH
PASSENGER SEAT CLIMATE CONTROL LED SEAT SWITCH
PPL
PRESET SWITCH
REAR AIR CONTROL
RED WIRE
RIGHT FRONT HEATED SEAT SWITCH
STEERING COLUMN)
STEERING SWITCH
TELEMATICS SWITCH
W/ INTELLIGENT CRUISE CONTROL
W/O CLIMATE CONTROL
W/O INTELLIGENT CRUISE CONTROL
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (3 of 3) -> W/O INTELLIGENT CRUISE CONTROL
