Infiniti QX60 I facelift (2016-2021) usb d- Wiring diagrams

This page contains all the electrical diagrams for the component. usb d-, in which he is found in the car Infiniti QX60 I facelift (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram usb d- (1 of 8)

Wiring diagram usb d- for Infiniti QX60 I facelift (2016-2021) (1 of 8)

Get access

AUX VIDEO - AV CONTROL UNIT BACK BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISPLAY DISPLAY CONTROL UNIT ENTER F DVD OUT LH- F DVD OUT RH- F DVD OUT SHIELD GRN WIRE GRY WIRE ILL INPUT 1 INPUT 2 LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MENU DOWN MENU UP NOT USED PNK WIRE REAR SEAT ENTERTAINMENT CIRCUIT RED WIRE RSE AUDIO IN LH- RSE AUDIO IN RH- RSE AUDIO SHIELD SHIELD SOUND SYSTEMS SOURCE SPD 8 P/R STEERING COLUMN) STEERING SWITCHES TAN WIRE TEL TEL SHIELD TEL SIG IN- UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) USB D- USB GND VBUS VIDEO SHIELD VOLUME DOWN VOLUME UP WHT WIRE YEL WIRE

Go to component -> Navigation circuit, except hybrid w/ center point audio (5 of 7) -> USB D-

Wiring diagram usb d- (2 of 8)

Wiring diagram usb d- for Infiniti QX60 I facelift (2016-2021) (2 of 8)

Get access

AUX VIDEO - AV CONTROL UNIT BACK BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CENTER SPEAKER COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISPLAY DISPLAY CONTROL UNIT ENTER F DVD OUT LH- F DVD OUT RH- F DVD OUT SHIELD GRN WIRE GRY WIRE GUIDE VOICE SHIELD GUIDE VOICE- ILL INPUT 1 INPUT 2 LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MENU DOWN MENU UP NOT USED PNK WIRE REAR SEAT ENTERTAINMENT CIRCUIT RED WIRE RSE AUDIO IN LH- RSE AUDIO IN RH- RSE AUDIO SHIELD SHIELD SOUND SYSTEMS SOURCE SPD 8 P/R STEERING COLUMN) STEERING SWITCHES TAN WIRE TEL TEL SHIELD TEL SIG IN- UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) USB D- USB GND VBUS VIDEO SHIELD VOLUME DOWN VOLUME UP WHT WIRE YEL WIRE

Go to component -> Navigation circuit, except hybrid w/o center point audio (4 of 6) -> USB D-

Wiring diagram usb d- (3 of 8)

Wiring diagram usb d- for Infiniti QX60 I facelift (2016-2021) (3 of 8)

Get access

AUX VIDEO - AV CONTROL UNIT BACK BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISPLAY DISPLAY CONTROL UNIT ENTER F DVD OUT LH- F DVD OUT RH- F DVD OUT SHIELD GRN WIRE GRY WIRE ILL INPUT 1 INPUT 2 LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MENU DOWN MENU UP NOT USED PNK WIRE REAR SEAT ENTERTAINMENT CIRCUIT RED WIRE RSE AUDIO IN LH- RSE AUDIO IN RH- RSE AUDIO SHIELD SHIELD SOUND SYSTEMS SOURCE SPD 8 P/R STEERING COLUMN) STEERING SWITCHES TAN WIRE TEL TEL SHIELD TEL SIG IN- UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) USB D- USB GND VBUS VIDEO SHIELD VOLUME DOWN VOLUME UP WHT WIRE YEL WIRE

Go to component -> Navigation circuit, hybrid (5 of 7) -> USB D-

Wiring diagram usb d- (4 of 8)

Wiring diagram usb d- for Infiniti QX60 I facelift (2016-2021) (4 of 8)

Get access

AUX VIDEO - AV CONTROL UNIT BACK BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISPLAY DISPLAY CONTROL UNIT ENTER F DVD OUT LH- F DVD OUT RH- F DVD OUT SHIELD FUSE 65 FUSE, FUSIBLE LINK, RELAY BOX 2 GRN WIRE GRY WIRE GUIDE VOICE SHIELD GUIDE VOICE- HOT AT ALL TIMES ILL INPUT 1 INPUT 2 LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MENU DOWN MENU UP NOT USED PNK WIRE REAR SEAT ENTERTAINMENT CIRCUIT RED WIRE RSE AUDIO IN LH- RSE AUDIO IN RH- RSE AUDIO SHIELD SHIELD SOUND SYSTEMS SOURCE SPD 8 P/R STEERING COLUMN) STEERING SWITCHES TAN WIRE TEL TEL SHIELD TEL SIG IN- UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) USB D- USB GND VBUS VIDEO SHIELD VOLUME DOWN VOLUME UP WHT WIRE YEL WIRE

Go to component -> Radio circuit, except hybrid base (3 of 4) -> USB D-

Wiring diagram usb d- (5 of 8)

Wiring diagram usb d- for Infiniti QX60 I facelift (2016-2021) (5 of 8)

Get access

AUX VIDEO - AV CONTROL UNIT BACK BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISPLAY DISPLAY CONTROL UNIT ENTER F DVD OUT LH- F DVD OUT RH- F DVD OUT SHIELD GRN WIRE GRY WIRE ILL INPUT 1 INPUT 2 LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MENU DOWN MENU UP NOT USED PNK WIRE REAR SEAT ENTERTAINMENT CIRCUIT RED WIRE RSE AUDIO IN LH- RSE AUDIO IN RH- RSE AUDIO SHIELD SHIELD SOUND SYSTEMS SOURCE SPD 8 P/R STEERING COLUMN) STEERING SWITCHES TAN WIRE TEL TEL SHIELD TEL SIG IN- UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) USB D- USB GND VBUS VIDEO SHIELD VOLUME DOWN VOLUME UP WHT WIRE YEL WIRE

Go to component -> Radio circuit, except hybrid bose w/ center point audio (5 of 7) -> USB D-

Wiring diagram usb d- (6 of 8)

Wiring diagram usb d- for Infiniti QX60 I facelift (2016-2021) (6 of 8)

Get access

AUX VIDEO - AV CONTROL UNIT BACK BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CENTER SPEAKER COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISPLAY DISPLAY CONTROL UNIT ENTER F DVD OUT LH- F DVD OUT RH- F DVD OUT SHIELD GRN WIRE GRY WIRE GUIDE VOICE SHIELD GUIDE VOICE- ILL INPUT 1 INPUT 2 LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MENU DOWN MENU UP NOT USED PNK WIRE REAR SEAT ENTERTAINMENT CIRCUIT RED WIRE RSE AUDIO IN LH- RSE AUDIO IN RH- RSE AUDIO SHIELD SHIELD SOUND SYSTEMS SOURCE SPD 8 P/R STEERING COLUMN) STEERING SWITCHES TAN WIRE TEL TEL SHIELD TEL SIG IN- UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) USB D- USB GND VBUS VIDEO SHIELD VOLUME DOWN VOLUME UP WHT WIRE YEL WIRE

Go to component -> Radio circuit, except hybrid bose w/o center point audio (4 of 6) -> USB D-

Wiring diagram usb d- (7 of 8)

Wiring diagram usb d- for Infiniti QX60 I facelift (2016-2021) (7 of 8)

Get access

AUX VIDEO - AV CONTROL UNIT BACK BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM DISPLAY DISPLAY CONTROL UNIT ENTER F DVD OUT LH- F DVD OUT RH- F DVD OUT SHIELD GRN WIRE GRY WIRE ILL INPUT 1 INPUT 2 LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L MENU DOWN MENU UP NOT USED PNK WIRE REAR SEAT ENTERTAINMENT CIRCUIT RED WIRE RSE AUDIO IN LH- RSE AUDIO IN RH- RSE AUDIO SHIELD SHIELD SOUND SYSTEMS SOURCE SPD 8 P/R STEERING COLUMN) STEERING SWITCHES TAN WIRE TEL TEL SHIELD TEL SIG IN- UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) USB D- USB GND VBUS VIDEO SHIELD VOLUME DOWN VOLUME UP WHT WIRE YEL WIRE

Go to component -> Radio circuit, hybrid (5 of 7) -> USB D-

Wiring diagram usb d- (8 of 8)

Wiring diagram usb d- for Infiniti QX60 I facelift (2016-2021) (8 of 8)

Get access

ACC DET IN AV GND BLK WIRE BLU WIRE CEC LINE CONN SHIELD CONN SHLD CONT GND D OUT DDC CLK DDC DATA DIN GRN WIRE HOT PLUG DET HOT PLUG DETECT HYBRID EXCEPT HYBRID L-H/P PIN JACK GND LH L-H/P PIN JACK+ LH R-H/P PIN JACK + NCA WIRE PNK WIRE PWR GND R-H/P PIN JACK GND REAR AUXILIARY INPUT JACKS RED WIRE RH L-H/P PIN JACK+ RH R-H/P PIN JACK + RIGHT HEADREST DISPLAY UNIT SHIELD SHLD TAN WIRE TMDS DATA 0 - TMDS DATA 0 SHLD TMDS DATA 1 - TMDS DATA 1 SHLD TMDS DATA 2 - TMDS DATA 2 SHLD TMDS DATA CLK + TMDS DATA CLK SHLD USB D- USB GND VBUS VIDEO DISTRIBUTOR (UNDER CENTER CONSOLE) WHT WIRE YEL WIRE

Go to component -> Rear seat entertainment circuit (2 of 2) -> USB D-
